Display
5″ Touch Screen
Face Capacity
6,000
Palm Capacity
3,000
Card Capacity
10,000
Transaction Capacity
200,000
Functions
ID Card, ADMS, DNS, T9 Input, DST, Camera, 9-digit User ID, Advance Access Control, Groups, Holidays, Anti-passback, Record Query, Tamper Switch Alarm, Bell Scheduling, POE (Optional, IEEE 802.3at-2009)
Hardware
1GHz Dual Core CPU 1G RAM / 8G Flash 2MP WDR Low Light Camera Adjustable LED Supplement Lighting Rain Cover (Optional)
Communication
TCP/IP, Wi-Fi (Optional), Wiegand Input / Output, RS485
Access Control Interface
3rd-party Electric Lock, Door Sensor, Exit Button, Alarm Output, Aux. Input
Optional Card Module
IC / HID / iClass / Felica / Desfire EV1 / EV2 / Legic
Biometrics Algorithm
ZKFace V5.8 & ZKPalm V12.0
Ingress Protection Rating
IP66
Power Supply
Voltage: DC 12V Current: Max. 3A
Operating Humidity
10% to 90%
Operating Temperature
-30°C to 60°C
Dimension
103.83 * 212.41 * 50.60 (mm) (W*H*D)
Supported Software
ZKBio Access IVS
