APC Back-UPS Pro 550

Categories: , .

APC Back-UPS Pro 550

APC Back-UPS Pro 550 is an excellent device that reserve power capacity and runtime for connected devices that need UPS battery backup. It is a high performance computer and electronics UPS for premium power protection. The features like automatic voltage regulation ensure your critical application is available by correcting the low and high voltage conditions without using the battery. The UPS features quickly understand unit and power status with visual indicators. It has been tested and approved to work safely.

Features

  • Audible alarms
  • Automatic self-test
  • Battery failure notification
  • Automatic voltage regulation
  • LCD graphics display
  • USB connectivity
  • Protection from power surges and spikes

Customers can place the order online for APC Back UPS Pro 550 through Amaze Technologies.

Description
The Back-UPSPro 550 provides abundant battery backup power, so you can work through short and medium length power outages.
It safe guards your equipment against damaging surges and spikes that travel along utility and network lines. The Back-UPS

LCD (Liquid Crystal Display) gives the status of over 20 different utility and battery backup conditions.
Automatic Voltage Regulation (AVR) instantly corrects voltage fluctuations so you can work indefinitely through brownouts and overvoltages.
3 “Battery Backup & Surge Protected” Outlets keep CPU,monitor and another critical device running when the power goes out (including a “Master” outlet).
3 “Surge Only” Outlets protect printers, faxes or other equipment without reducing battery capacity (including two power-saving “Controlled” outlets).
Data Line Protection guards against surges and spikes traveling over Ethernet lines – up to 1000 Base-T (gigabit).
Push Button Circuit Breaker enables quick recovery from overloads.
Automatic Diagnostic Testing ensures your unit is ready when you need it.
PowerChute Software lets you use your computer to access additional power protection and management

Features:
Preserves your work, shuts down system during outages
Restarts your system, minimizing work disruptions
Enables customization of your Back-UPS settings
Monitors and displays power and battery status

Output
Output Power Capacity 330 Watts / 550 VA
Topology Line Interactive
Efficiency at Full Load / Half Load 77% / 84%
Waveform Type Stepped approximation to a sinewave
Output Connections (3) IEC 320 C13 (Battery Backup) (3) IEC 320 C13 (Surge Protection) (2) IEC Jumpers (Battery Backup)
Input
Nominal Input Voltage 230V
Input Connections IEC-320 C14
Input voltage range for main operations 176 – 282V
Batteries & Runtime
Battery Type Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Typical recharge time 12 hour(s)
Runtime for 100% load 3.2 (min)
Runtime for 75% load 6.0 (min)
Runtime for 50% load 11.8 (min)
Communications & Management
Interface Port(s) Optional Simple Signalling RS232 cable, USB
Control panel Multi-function LCD status and control console
Audible Alarm Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
