Cambium cnPilot e700 Enterprise Outdoor

Cambium cnPilot e700 Enterprise Outdoor

Cambium CN Pilot e700 Enterprise outdoor Omni wireless access point is powered with Multi User MIMO (MU-MIMO) 802.11ac wave2 technology for faster transmission. This outdoor wireless access point is perfect for applications that demand high capacity, such as in the industrial and enterprise campuses, hospitality, Public Wi-Fi and more. It features like controller-less roaming, dynamic channel selection, automatic transmit power control, band steering, and more essential features for easy Wi-Fi operations. It supports 512 max concurrent client associations and is secured with WPA-2 encryption. The access point is essential for today’s demanding high density outdoor Wi-Fi networks.

Features

  • Zero touch provisioning and configuration
  • Inventory tracking and monitoring
  • Supports max up to 512 user association
  • Offers more flexibility for both coverage and capacity
  • Increased performance
  • Affordable and no hidden charges
  • Integrated troubleshooting

Customers in UAE can place the order online for Cambium CN Pilot e700 Enterprise outdoor Omni wireless access point through Amaze Technologies.

Description
ACCESS POINT SPECIFICATIONS
Frequency Bands
2.4 GHz: 2.4 – 2.4835 GHz Channels 1 – 13 (ETSI/CE), Channels 1 – 11 (US) 5 GHz: 5.15 – 5.85 GHz
SSID Security
WPA-2 (802.11i): WPA2-Enterprise (802.1x/EAP) & WPA2-Preshared-keys, Open
Max SSIDs
16
Max Concurrent Clients
512
Max Data Rates
2.4GHz: 400Mbps, 5GHz: 1733Mbps
Ethernet Ports
Dual Gigabit Ethernet ports (2 x 10/100/1000Base-T)
Antenna
Integrated Omni
Antenna Gain
8 dBi (2.4 GHz and 5 GHz)
Power Consumed
Typical 18W. Max 24.6W
Dimensions (cm)
315 x 215 x 66 mm (without bracket)
Weight
3.174 lbs (1700 gms) without bracket
WI-FI FEATURES
Controller modes
• Autonomous Controller-less operations (E.g.: roaming) • Cloud Managed • On-premise virtualized controller
Secure WLAN
WPA-TKIP, WPA2 AES, 802.1x 802.11w (Protected Management Frames)
Hotspot 2.0
Passpoint supported
Captive Portal
• cnMaestro Controller • Redirection to external RADIUS •Stand-alone AP based • Server DNS logging
Authentication
• RADIUS based 802.1x including EAP-SIM/AKA, EAP-PEAP, EAP-TTLS, and EAP-TLS • MAC auth (local database or External RADIUS server)
Scheduled SSID
Turn SSID ON/OFF on a daily/weekly/time of day basis
Guest Access
Yes. With Active Directory Integration • Vouchers • Rate limiting • Splash page creation on cnMaestro
cnMAESTRO WI-FI CONTROLLER
Common Manager
Single pane of glass: Controller for Wi-Fi and network manager for ePMP and PMP wireless backhaul products
On-Boarding
Secure zero touch fast on-boarding
Provisioning
Easy zero touch virtual network provisioning Provision before install (pre-provision)
Device Inventory
Inventory tracking
Configuration
GUI based configuration or template based configuration options
