D-Link DGS-1024D

Get the blazing speed of Gigabit Ethernet with the D-Link GigaExpress DGS-1024D, an 24-port 10/100/1000Mbps Gigabit Switch that delivers power, performance, and reliability in one cost-effective, space-saving design. Increase the speed of your network server and backbone connections, or make Gigabit to the desktop a reality. Power users in the office, workgroup, or creative production environment can now move large, bandwidth-intensive files faster. Transfer graphics, CGI, CAD, or multimedia files across the network instantly. The versatile and compact 1RU height design of the DGS-1024D enables the device to be rackmounted in a standard 19 inch rack, while conserving valuable rack space.

Key Features
ƒ Innovative 2nd Generation D-Link Green
Technology
ƒ Inexpensive Gigabit solution for SOHO/
SMB
ƒ Silent, fanless design
ƒ Auto MDI/MDI-X crossover for all ports
ƒ Store-and-forward switching scheme
ƒ Full/half-duplex for Ethernet/Fast
Ethernet speeds
ƒ IEEE 802.3x Flow Control
ƒ Supports 9,600Bytes Jumbo Frames
ƒ Supports IEEE 802.1p QoS (4 Queues,
Strict Mode)
ƒ Supports Cable Diagnostics Function
ƒ RoHS compliant
ƒ Plug-and-play installation
NUMBER OF PORTS
ƒ DGS-1016D: 16 Gigabit ports
ƒ DGS-1024D: 24 Gigabit ports
SWITCHING FABRIC
ƒ DGS-1016D: 32 Gbps switching fabric
ƒ DGS-1024D: 48 Gbps switching fabric
Standards
ƒ IEEE 802.3 10BASE-T Ethernet (twistedpair copper)
ƒ IEEE 802.3u 100BASE-TX Fast Ethernet
(twisted-pair copper)
ƒ IEEE 802.3ab 1000BASE-T Gigabit
Ethernet (twisted-pair copper)
ƒ ANSI/IEEE 802.3 NWay auto-negotiation
ƒ IEEE 802.3x Flow Control
ƒ IEEE 802.1p QoS (4 queues, strict mode)
Protocol
ƒ CSMA/CD
Data Transfer Rates
ƒ Ethernet:
ƒ 10 Mbps (half duplex)
ƒ 20 Mbps (full duplex)
ƒ Fast Ethernet:
ƒ 100 Mbps (half duplex)
ƒ 200 Mbps (full duplex)
ƒ Gigabit Ethernet:
ƒ 2000 Mbps (full duplex)
Topology
ƒ Star
Network Cables
ƒ 10BASE-T:
ƒ UTP CAT 3, 4, 5/5e (100 m max.)
ƒ EIA/TIA-586 100-ohm STP (100 m max.)
ƒ 100BASE-TX, 1000BASE-T:
ƒ UTP CAT 5/5e (100 m max.)
ƒ EIA/TIA-568 100-ohm STP (100 m max.)
Media Interface Exchange
ƒ Auto MDI/MDI-X adjustment for all ports
LED Indicators
ƒ Per port: Link/Activity/Speed
ƒ Per device: Power
Transmission Method
ƒ Store-and-forward
MAC Address Table
ƒ 8K entries per device
MAC Address Learning
ƒ Automatic update
Packet Filtering/Forwarding Rates
(half duplex)
ƒ Ethernet: 14,880 pps per port
ƒ Fast Ethernet: 148,800 pps per port
ƒ Gigabit Ethernet: 1,488,000 pps per port
RAM Buffer
ƒ 512 KB per device
Power Consumption
ƒ DGS-1016D
ƒ Standby: 3.8 watts
ƒ Maximum: 11.7 watts
ƒ DGS-1024D
ƒ Standby: 5.1 watts
ƒ Maximum: 17.1 watts
Heat Dissipation
ƒ DGS-1016D
ƒ Standby: 12.96 BTU/h
ƒ Maximum: 39.9 BTU/h
ƒ DGS-1024D
ƒ Standby: 17.39 BTU/h
ƒ Maximum: 58.31 BTU/h
ACOUSTICS
ƒ 0 dB
MTBF
ƒ DGS-1016D: 828,109 hours
ƒ DGS-1024D: 642,569 hours
Operating Temperature
ƒ 0˚ to 40˚ C (32˚ to 104˚ F)
STORAGE TEMPERATURE
ƒ -10˚ to 70˚ C (14˚ to 158˚ F)
OPERATING HUMIDITY
ƒ 10% to 90% RH non-condensing
Storage Humidity
ƒ 5% to 90% RH non-condensing
Dimensions
ƒ 280 x 180 x 44 mm
(11.02 x 7.09 x 1.73 inches)
Weight
ƒ DGS-1016D: 1.352 kg (2.98 lbs)
ƒ DGS-1024D: 1.476 kg (3.25 lbs)
CERTIFICATIONS
ƒ FCC Class A
ƒ ICES-003 Class A
ƒ CE Class A
ƒ C-Tick Class A
ƒ VCCI Class A
ƒ cUL
ƒ CB
D-Link Corporation
