Dell New PowerEdge R6415 Rack Server

Dell New PowerEdge R6415 Rack Server
Bring high-density computing to your data center with the PowerEdge R6415. This efficient single-socket rack server is specially tuned for virtualization and scale-out software-defined storage. Benefit from rich storage performance with up to 10 NVMe drives. With the enterprise-class AMD EPYC™ processor, the R6415 provides up to 32 cores per processor while reducing bottlenecks with up to 1 terabyte of memory and 128 PCIe lanes

Description
Tech Specs & Customization
Processor
1x Full AMD SP3 processor stack TDP, up to 180W, up to 32 cores

Bezel
Optional LCD bezel or Security Bezel

Dimensions & Weight
Depth:
8×2.5” is 60.65cm (23.88 in.)
4×3.5” and 10X2.5” is 65.72cm (25.87 in.)

Width:
43.4 cm (17.09 in.)

Height:
4.28 cm(1.69 in)

Drive Bays
Front drive bays: Up to 10 x 2.5″ SAS/SATA/NVME or up to 8 x 2.5″ SAS/SATA or up to 4 x 3.5″ SAS/SATA HDD

Embedded Management
iDRAC9 with Lifecycle Controller (no power capping)
iDRAC Direct
iDRAC REST API with Redfish
Quick Sync 2 BLE/wireless module

Integrations and Connections
Microsoft® System Center, VMware® vCenter,™ BMC Software (available from BMC)
Nagios Core and Nagios XI, HPE Operations Manager i (OMi)

I/O and Ports
Network daughter card options:
Optional LOM:
2 x 1GE or 2 x 10GE or 2 x 10GE SFP+

Front ports:
Video, 1 x USB 2.0, dedicated iDRAC Direct USB

Rear Ports:
LOM: 2 x 1GE, Video, Serial, 2 x USB 3.0, dedicated iDRAC network port
Riser options with up to 2 x Gen3 slots; 2 x16 lanes

Memory*
16 DDR4 DIMM slots, Supports RDIMM, LRDIMM

OpenManage Software
OpenManage Enterprise (available soon)
OpenManage Essentials
OpenManage Mobile

Power Supplies
Platinum 550W, Bronze 450W

Recommended Support
Choose Dell ProSupport Plus for critical systems or Dell ProSupport for premium hardware and software support for your PowerEdge solution. Consulting and deployment offerings are also available. Contact your Dell representative today for more information. Availability and terms of Dell Services vary by region.

Supported Operating Systems
Microsoft Windows Server® 2016
Red Hat® Enterprise Linux 7.4
VMware® vSphere 2016 U1 (ESXi 6.5 U1)
Microsoft Windows Server® 2012 R2

Storage Controllers
Internal Controllers:
PERC H330, H730p, H740p, HBA330

Boot Optimized Storage System:
HW RAID 2 x M.2 + Internal USB + Internal Dual SD Module

External PERC (RAID):
H840

External HBAs (non-RAID):
12Gbps SAS HBA
12Gbps PERC9 or 10 series, mini PERC x8 slot

Security
TPM 1.2/2.0 optional
Cryptographically signed firmware
Silicon Root of Trust, Secure Boot, System Lockdown, Secure Erase

Drive transformation with Dell EMC PowerEdge servers
Data center evolution starts with modern platforms that scale easily and are optimized for application performance. The PowerEdge R6415 is built upon a scalable system architecture and provides choice and flexibility to meet performance demands.

Simplify deployment and easily scale from 3 to 1000+ nodes for software-defined storage with Dell EMC ScaleIO Ready Node
Maximize storage performance with up to 10 NVMe SSDs
Scale compute resources with the AMD EPYC microprocessor delivering up to 128 PCIe lanes for high bandwidth and low-latency access
