Dell PowerEdge R230 Rack Server E3-1220 v6

Categories: , .

Dell PowerEdge R230 Rack Server E3-1220 v6

Dell PowerEdge R230 Rack Server E3-1220 v6 (3.0 GHz, 4C/4T), 32GB UDIMM, 4x1TB 7.2K RPM SATA 6Gbps 3.5 Inch Cable Hard Drive, DVD-RW, PERC H330 RAID) | R230
  • Processor : Intel Xeon E3-1220 v5 3.0GHz, 8M cache, 4C/4T
  • Base : PowerEdge R230 Server
  • Memory : 16GB (1x16GB) 2400MT/s DDR4 ECC UDIMM
  • Hard Drive : 2TB 7.2K RPM NLSAS 12Gbps 3.5in Cabled Hard Drive
  • Power : 250W cabled PSU
  • RAID Controllers : PERC H330
  • Chipset : Intel C236
  • Slots : 2 x PCIe 3.0 slots: x16 slot, full height (1×8 PCIe 3.0)+ x8 slot, low profile (1×4 PCIe 3.0)
  • Network Controller : Broadcom BCM5720
  • Device Access : 5 Total USB:
  • Rear: 2 x USB 3.0 ports
  • Front: 2 x USB 2.0 ports
  • Internal: 1 x USB 3.0 port
  • Dimensions : Depth without bezel: 495.0 mm (19.5 in)
  • Depth with bezel: 551.3 mm (21.7 in)
  • Height: 42.8 mm (1.68 in)
  • Width without rack latches: 434.0 mm (17.08 in)
  • Width with rack latches: 482.4 mm (18.99 in)

Get organized and become more productive

Consolidate data from multiple laptops or desktops onto a single server with up to 4 x internal 3.5" cabled or hot-plug HDD.

Ensure fast response times with the latest quad core Intel Xeon E3-1200 v6 product family, as well as flexible dual core processor options including Intel Pentium, Intel Core i3, or Intel Celeron.

Adapt to changing workload conditions with a virtualization-ready server supporting Citrix XenServer, Microsoft Windows Server with Hyper-V, VMware vSphere ESXi, and Red Hat Enterprise Virtualization.

Accelerate application performance

Drive greater memory performance and expand capacity up to 64GB through time with 4 x DIMM slots and enhanced DDR4 memory, offering 50% faster clock speed than previous-generation DDR3 which is 12.5% faster than the initial 2133 MT/s implementation of DDR4.

Boost data throughput with 2 x PCIe Gen 3.0 slots driving 2x data throughput compared to Generation 2.0.

Drive 2x IOPS performance with the PowerEdge PERC9 RAID Controller compared to the previous-generation PowerEdge R220 equipped with PERC8.

Reliable, worry-free operation

Deploy rapidly and turn the server over for productive work sooner with Dell OpenManage systems management solutions.

Easily monitor system health and behavior with a simple, intuitive Dell OpenManage Essentials console.

Save IT administrator time by automating firmware updates — up to 92% reduction in firmware update time using Repository Manager auto-updates compared to manual updates.
