GIGABIT PERFORMANCE
Minimize transfer times and stream high-bandwidth files to connected devices without interference.
PLUG-AND-PLAY CONVENIENCE
Instantly extend your office network with a quick and easy installation
QUALITY OF SERVICE (QOS) TRAFFIC PRIORITIZATION
Prioritize traffic to particular devices or activities & maintain mission-critical data throughput regardless of network congestion
AUTO-SENSING PORTS
Automatically optimize speed for each connected device.
TECHNICAL SPECS
Model Name:
LGS116P
Network Standards:
IEEE 802.3
IEEE 802.3u
IEEE 802.3x
IEEE 802.3ab
IEEE 802.3az
IEEE 802.3af
IEEE 802.3at (PoE+)
Ports:
16-port switch with 8 PoE+ ports (first 1–8 ports) and dedicated PoE power budget of 80 W
LEDs:
Link, speed, activity, and PoE indicators
Performance:
Full line rate and forwarding rate of 64B frame at:
1.488 Mpps for 1000M port
0.1488 Mpps for 100M port
0.01488 Mpps for 10M port
Maximum Power Consumption:
5.18 W / 13.41 W
MAC Address Table Size:
8,000 entries
Bandwidth:
32 Gbps (non-blocking)
Fans:
None
Minimum System Requirements:
Connected devices need Ethernet connectivity and Ethernet cables.
Dimensions (LxWxH):
280 x 120 x 25 mm (11.0 x 4.7 x 1.0 in.)
Weight:
0.902 kg (1.99 lbs)
Power:
54 VDC, 1.66 A
Power Consumption:
4.52 W / 11.31 W
Power Consumption:
4.52 W / 11.31 W
Power Saving:
Cable connected detection, sleep mode
Power Supply:
External
Operating Temperature:
0–50°C (32–122°F)
Storage Temperature:
-40–70°C (-40–158°F)
Operating Humidity:
10–90% (non-condensing)
Storage Humidity:
10–90% (non-condensing)
Mounting:
Wall
Quality Of Service:
802.1p and DSCP
Regulatory Compliance:
FCC Class A, CE
Warranty and Support:
5 Year Warranty
