MikroTik CRS109-8G-1S-2HnD-IN

Category: .

MikroTik CRS109-8G-1S-2HnD-IN

Cloud Router Switch 109-8G-1S-2HnD-IN is new “small size low cost” member of our CRS series. It comes with eight Gigabit Ethernet ports and high power 2.4GHz wireless. Product supports 10-57V and is 802.3af/at compliant!

Our CRS series combines the best features of a fully functional router and a Layer 3 switch, is powered by the familiar RouterOS. All the specific Switch configuration options are available in a special Switch menu, but if you want, ports can be removed from the switch configuration, and used for routing purposes.

Specifications
Details
Product code CRS109-8G-1S-2HnD-IN
Architecture MIPSBE
CPU AR9344
CPU core count 1
CPU nominal frequency 600 MHz
Dimensions 200x145x45mm
License level 5
Operating System RouterOS
Size of RAM 128 MB
Storage size 128 MB
Storage type NAND
Tested ambient temperature -40°C to 65°C
Suggested price $149.00
Powering
Details
PoE in Passive PoE
802.3af support yes
PoE in input Voltage 10-57 V
Number of DC inputs 2 (PoE-IN, DC jack)
DC jack input Voltage 10-57 V
Max power consumption 13 W
Wireless
Details
Wireless 2.4 GHz Max data rate 300 Mbit/s
Wireless 2.4 GHz number of chains 2
Wireless 2.4 GHz standards 802.11b/g/n
Antenna gain dBi for 2.4 GHz 4
Wireless 2.4 GHz chip model AR9344
Wireless 2.4 GHz generation Wi-Fi 4
Ethernet
Details
10/100/1000 Ethernet ports 8
Fiber
Details
SFP DDMI yes
SFP ports 1
Peripherals
Details
Serial port RJ45
Number of USB ports 1
USB Power Reset Yes
USB slot type microUSB type AB
Max USB current (A) 1.5
Other
Details
PCB temperature monitor Yes
Voltage Monitor Yes
Certification & Approvals
Details
Certification CE/RED, FCC, EAC, ROHS
Wireless specifications
2.4 GHz Transmit (dBm) Receive Sensitivity
1MBit/s 29 -97
11MBit/s 28 -90
6MBit/s 30 -96
54MBit/s 25 -76
MCS0 30 -96
MCS7 23 -73
