Professional Display QBN-W Series 75”

Professional Display QBN-W Series 75”

Revitalize Productive Collaboration: Samsung’s QBH-TR / QBN-W e-boards offer a versatile, all-in-one arena for improved collaboration. Enhanced touch technology, the intuitive MagicIWB S5 solution and UHD picture quality come together to boost productivity and collaboration by facilitating engaging, efficient interaction.
Enhance Touch, Enhance Capacity: Leverage heightened touch functionality for a smooth and versatile digital writing experience. Up to four users can write simultaneously using the provided pen or virtually any other tool.
Elevate Collaboration Quality: The embedded MagicIWB S5 solution facilitates discussion management and organization with an intuitive interface for quick access to vital collaborative functionalities such as screen mirroring and real-time notation saving.
Switch Sources Seamlessly: Through the Working Screen function, users can quickly switch between multiple screens, such as the whiteboard, internet browser and connected input sources, with just a few touches.

  • UHD E-Board
  • Magnetic pen
  • Slim Design
Retrieve and Control Content Remotely

Pull and edit content on remote laptops directly through the central screen utilizing touch functionality. The powerful Knox system secures the Remote Workspace connection to protect against information leakage and meddling.

Connect with Convenience

Each e-board offers a wide range of connections including HDMI, DVI-D, DP and USB ports, where users can load, share and revise content directly from their personal devices.

Amplify Visual Presentation

Bring collaborative ideas to life through advanced UHD picture quality. Through ultra-high resolution, ensure all notations and introduced content are clear and legible for every participant.

Maintain Organization with Style

Drive more organized collaboration with a sleek, sophisticated design. The magnetic side pen holder and frontal connection ports keep needed functions within reach, without the mess.

Specification

Display
  • Diagonal Size : 75"
  • Panel Type : New Edge, 60Hz
  • Resolution : 3,840 x 2,160
  • Pixel Pitch (HxV, mm) : 0.42975(H) x 0.42975(V)
  • Brightness (Typical, cd/m2) : 250
  • Contrast Ratio : 6,000:1
  • Viewing Angle (H/V) : 178/178
  • Response Time : 8ms
  • Color Gamut : ‎72%‎
  • Glass Haze : ‎Panel 0.02, Touch glass 0.15%‎
  • H-Scanning Frequency : 30~81kHz
  • Maximum Pixel Frequency : 594Mhz
  • V-Scanning Frequency : 48~75Hz
  • Dynamic Contrast Ratio : Mega
Connectivity
  • HDMI In : 3
  • DVI In : 1(DVI-D)
  • USB : 3
  • Audio In : Yes
  • Audio Out : Stereo Mini Jack
  • RS232 In : Yes
  • RS232 Out : Yes
  • RJ45 In : Yes
  • RJ45 Out : No
  • IR In : Yes
  • HDBaseT In : No
  • WiFi : Yes
  • 3G Dongle : No
  • Bluetooth : No
Power
  • Power Supply : AC 100~240V 50/60Hz
  • Power Consumption (On Mode, W) : 220
  • Power Consumption (Sleep Mode, W) : ‎0.5‎
Dimension
  • Set Dimension (WxHxD, mm) : ‎1741.5 x 1012.1 x 81.2‎
  • Package Dimension (WxHxD, mm) : ‎1905 x 1175 x 307‎
Weight
  • Set Weight (kg) : ‎57.4‎
  • Package Weight (kg) : ‎69.5‎
Mechanical Specification
  • VESA Mount (mm) : ‎400 x 400‎
  • Bezel Width (mm) : T(33.0), B(48.9),LR(33.0)
  • Frame Material : Non-Glossy
Operation Conditions
  • Temperature : 0℃~ 40℃
  • Humidity : 10 ~ 80%, non-condensing
General Feature
  • External Memory Slot : No
Optional Feature
  • Mount : Yes (WMN6575SE)
  • Stand : No
