Samsung Professional Display DB32E

Samsung Professional Display DB32E

Sleek, professional signage that supports 16-hour-per-day functionality

Professional-grade, cost-effective display solution that supports 16/7 operation and 350-nit brightness
All-in-one display solution with embedded MagicInfo Player S3, no need for external media players
Simplified content management with built-in Wifi and an easy-to-use mobile application

Panel
Diagonal Size
32"

Type
60Hz D-LED BLU
Resolution
1920*1080 (Full HD)

Pixel Pitch(mm)
0.12125(H) x 0.36375(V)
Active Display Area(mm)
698.4(H) x 392.85(V)

Brightness(Typ.)
350 nit

Contrast Ratio
5000:1

Viewing Angle(H/V)
178:178

Response Time(G-to-G)
8ms
Display Colors
16.7 M
Color Gamut
72%
Operation Hour
16/7

Haze
2%
Display
Dynamic C/R
50,000:1
H-Scanning Frequency
30 ~ 81kHZ
V-Scanning Frequency
48 ~ 75HZ
Maximum Pixel Frequency
148.5MHz
Sound
Speaker Type
Built in Speaker(10W x 1)
Connectivity
Input
RGB
Analog D-SUB, DVI-D(HDMI Common)
Video
HDMI1 Component(CVBS Common)

HDCP
HDCP 1.4
Audio
Stereo mini Jack
USB
USB 2.0 x 1
Output
Audio
Stereo mini Jack
External Control
RS232C(in/out) thru stereo jack, RJ45

External Sensor
IR, Ambient Light
Tuner
Yes(only for NA/KR)
Power
Type
Internal

Power Supply
AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption
Max[W/h]
77.0

Typical[W/h]
54 (w/w), 30 (us), 57 (kor)

BTU(Max)
262.57

Sleep mode
less than 0.5W
Off mode
less than 0.5W
Mechanical Specification
Dimension (mm)
Set
721.4 X 420.3 X 49.9

Package
815 X 491 X 132
Weight (kg)
Set
4.8

Package
5.9
VESA Mount (mm)
200*200mm

Protection Glass
N/A

Stand Type
Foot Stand (Optional)

Media Player Option Type
Embbeded, SBB (Not attachable)

Bezel Width (mm)
10.5 (Top/Side), 15.0 (Bottom)
Operation
Operating Temperature
0.0 ℃ ~ 40.0 ℃

Humidity
10.0 % ~ 80.0 %
Feature
Key Features
Slim & Light LFD with Built-in MagicInfo Player S3, SSSP 3.0
Special Features
H/W: Super Clear Coating, Temperature Sensor, Pivot Display, Button Lock, Clock Battery(168hrs Clock Keeping), Built in Speaker(10W x 1), WiFi Module Embedded, SD Card Slot S/W: Magic Clone(to USB), Auto Source Switching & Recovery, RS232C/RJ45 MDC,Plug and Play (DDC2B), PIP/PBP, Image Rotation, Built In MagicInfo Player S3, Firmware Update by Network, LFD New Home Screen, Predefined Template for Vertical Usage, Multi Channel, Mobile Control, Event Schedule, Backup Player, PC-less Touch, MagicPresenter
Internal Player
Processor
Cortex-A9 1GHz Quad Core CPU

On-Chip Cache Memory
L1 (I/D) : 32KB / 32KB L2 (Unified) : 1MB

Clock Speed
1GHz CPU Quad

Main Memory Interface
1.5GB 48bit DDR3-933 (1866MHz)
Graphics
2D & 3D Graphics Engine - Up to 1920x1080. 32bpp - Supports OpenGL ES

Storage (FDM)
8GB (2.65GB Occupied by O/S, 5.35GB Available, )

Multimedia
Video Decoder - MPEG-1/2, H.264/AVC (Dual) - VC-1, JPEG, PNG,VP8 Audio DSP (Decoder) - AC3 (DD), MPEG, DTS and etc.

IO Ports
USB 2.0
Operating System
Samsung Proprietary OS(VDLinux)
Certification
Safety
CB (Europe) : IEC60950-1/EN60950-1 CCC (China) : GB4943.1-2011 PSB (Singapore ) : PSB+IEC60950-1 NOM (Mexico ) : NOM-001-SCFI-1993 IRAM (Argentina ) : IRAM+IEC60950-1 SASO (Saudi Arabia ) : SASO+IEC60950-1 BIS(India) : IEC60950-1 / IS13252 NOM(Mexico) : Tuner : NOM-001-SCFI-1993 Tunerless : NOM-019-SCFI-1998 KC(Korea) : K 60950-1 EAC(Russia) : EAC+IEC60950-1 INMETRO(Brazil) : INMETRO+IEC60950-1 BSMI(Taiwan) : BSMI+IEC60950-1 RCM(Australia) : IEC60950-1/AS/NZS 60950-1 CSA (Canada) : cUL UL(USA) : cUL60950-1 TUV (Germany) : CE NEMKO (Norway) : CE

EMC
FCC (USA) Part 15, Subpart B Class A CE (Europe) : EN55022:2006+A1:2007 EN55024:1998+A1:2001+A2:2003 VCCI (Japan) : VCCI V-3 /2010.04 Class A KCC/EK (Korea) : Tuner : KN13 / KN20 Tunerless : KN22 / KN24 BSMI (Taiwan) : CNS13438 (ITE EMI) Class A / CNS13439 (AV EMI) / CNS14409 (AV EMS) / CNS14972 (Digital) C-Tick (Australia) : AS/NZS CISPR22:2009 CCC(China) :GB9254-2008 GB17625.1-2012 GOST(Russia/CIS) : GOST R 51317 Series, GOST 22505-97 EN55022:2006+A1:2007 EN55024:1998+A1:2001+A2:2003
Accessory
Included
Quick Setup Guide, Regulatory Guide, Warranty Card, D-Sub cable, Power Cord, Remote Controller, Batteries, RS232C(IN) adapter, Cover-Jack, Screw (M3L8, 1EA) (M4L8, 4EA)
Optional
Stand
STN-L3240E

Mount
WMN4070SD

Specialty
CML400D (Ceiling Mount)
Media Player
Media Player
Media Player
SBB (Not attachable/Optional)
