2MP Full HD Vandal-Resistant Network IR Dome
The SNV-L6083R vandal-resistant dome camera from Hanwha Techwin’s Wisenet Lite series features 2 megapixel Full HD video, varifocal lens and IR LEDs that provide visibility up to 65ft away. Powered by PoE it can withstand conditions down to -22°F and the SDHC memory card slot allows on-camera recording up to 32GB.

VIDEO
Imaging Device 1/2.9" 2.19M CMOS
Total Pixels 2,000(H) x 1,121(V)
Eective Pixels 1,984(H) x 1,105(V)
Scanning System Progressive
Min. Illumination Color : 0.095Lux (1/30sec, F1.4), 0.002Lux (2sec, F1.4) B/W : 0Lux (IR LED on)
LENS
Focal Length (Zoom Ratio) 2.8 ~ 12mm (4.3x) varifocal
Max. Aperture Ratio F1.4
Angular Field ofView H : 103.8˚(Wide) ~ 32.4˚(Tele) / V : 53.7˚(Wide) ~ 18.4˚(Tele)/
D : 121.9˚(Wide) ~ 37.1˚(Tele)
Min. Object Distance 0.5m (1.64ft)
Focus Control Manual
Lens Type DC auto iris
Mount Type Board type
PAN / TILT / ROTATE
Pan / Tilt/ Rotate Range 0° ~ 350° / 0° ~ 67°/ 0° ~ 355°
OPERATIONAL
IRViewable Length 20m (65.62ft)
Camera Title O / On (Displayed up to 15 characters)
Day & Night True Day & Night
Backlight Compensation O / BLC
Contrast Enhancement (DWDR) SSDR (O / On)
Digital Noise Reduction SSNR (O / On)
Motion Detection O / On (4ea rectangular zones)
Privacy Masking O / On (6ea rectangular zones)
Gain Control O / Low / Middle / High
White Balance ATW / AWC / Manual / Indoor / Outdoor
LDC (Lens Distortion Correction) O / On (5 levels with min / max)
Electronic Shutter Speed Minimum / Maximum / Anti icker
Flip / Mirror Flip / Mirror/ Hallway view
IntelligentVideo Analytics Motion detection with metadata, Tampering
AlarmTriggers Motion detection, Tampering detection, SD card error, NAS error
Alarm Events File upload via FTP and E-mail, Localstorage recording at event, Notication via E-mail
NETWORK
Ethernet RJ-45 (10/100BASE-T)
Video Compression Format H.264, MJPEG
Resolution 1920 x 1080, 1280 x 960, 1280 x 720, 1024 x 768,
800 x 600, 720 x 576, 640 x 480, 320 x 240
Max. Framerate
H.264 : Max. 30fps at all resolutions
MJPEG : Max. 1fps at 1920 x 1080, 1280 x 960, 1280 x 720, 1024 x 768,
Max. 15fps at other resolution
VideoQuality Adjustment H.264 : Target bitrate level control, MJPEG : Quality level control
Bitrate Control Method H.264 : CBR or VBR, MJPEG : VBR
Streaming Capability Multiple streaming (Up to 3 proles)
Audio I/O Line in
Audio Compression Format G.711 u-law / G.726 selectable
G.726 (ADPCM) 8KHz, G.711 8KHz, G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps
Audio Communication Uni-directional audio
IP IPv4, IPv6
Protocol TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour
Security
HTTPS(SSL) login authentication, Digest login authentication
IP address ltering, User accesslog, 802.1x authentication
Streaming Method Unicast / Multicast
Max. User Access 6 users at unicast mode
Storage
micro SD/SDHC max. 32G, NAS
- Motion imagesrecorded in the SD memory card can be downloaded
- Manual recording at local PC
Application Programming Interface ONVIF Prole S/G, SUNAPI (HTTP API)
Webpage Language
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch,
Croatian, Hungarian, Greek, Norwegian, Finnish
WebViewer
Supported OS : Windows XP / VISTA / 7 / 8 / 8.1, MAC OS X 10.7 ~ 10.10
Supported Browser : Microsoft Internet Explorer (Ver. 8 ~ 11), Mozilla Firefox (Ver. 9 ~ 35),
Google Chrome (Ver. 15 ~ 40), Apple Safari (Ver. 8.0.2(Mac OS X
10.10), 7.0.6 (Mac OS X 10.9), 6.0.2 (Mac OS X 10.8, 10.7 only), 5.1.7)
* Mac OS X only
Central Management Software SmartViewer
ENVIRONMENTAL
OperatingTemperature / Humidity
-30°C ~ +55°C (-22°F ~ +131°F)/ Lessthan 90% RH * Start up should be done at above -20°C (-4°F)
Storage Temperature / Humidity -30°C ~ +60°C (-22°F ~ +140°F)/ Lessthan 90% RH
Ingress Protection IP66
Vandal Resistance IK10
ELECTRICAL
InputVoltage / Current PoE (IEEE802.3af, Class2)
Power Consumption Max. 5.8W
MECHANICAL
Color/ Material Ivory / Metal
Dimensions(WxH) Ø137.0 x 106.1mm (Ø5.39" x 4.18")
