BODY TEMPERATURE DETECTION SPECIFICATIONS
Preventative Measures
Mask detection / Body temperature detection
Temperature Measurement Distance
50cm to 120cm (1.64ft to 3.94ft)
Temperature Measurement Accuracy
±0.3°C(±0.56°F)
Temperature Measurement Range
20°C to 50°C (68°F to 122°F)
SPECIFICATIONS
User Capacity
30,000 (optional 50,000)
Face Capacity
30,000 (optional 50,000)
Card Capacity
30,000 (optional 50,000)
Palm Capacity
3,000 (optional 6,000)
Transaction Capacity
1,000,000
CPU
64bit Eight Core Customized Computer Vision CPU
Storage
2GB LPDDR3 / 16GB eMMC
Screen Size
7-inch Touch Screen 720*1280 Pixels
Camera
2MP Binocular Camera
Communication
TCP/IP, USB Host, RS485, Wiegand Input,Wiegand Output, Wi-Fi, Bluetooth, 4G
WLAN: 2.4G, 802.11 b/g/n
Bluetooth: BT2.1+EDR/3.0/4.1 LE/4.2 BLE
LTE FDD: B1/B2/B3/B4/B5/B7/B8/B20/B28
LTE TDD: B38/B39/B40/B41
WCDMA: B1/B2/B4/B5/B8
GSM: 850/900/1800/1900MHz
Access Control Interface
RS485 (OSDP v2.1.7), Wiegand In/Out, Lock Relay Output, Exit Button, Alarm Output, Auxiliary Input, Door Sensor, External Bell
Palm
FAR ≤0.01%; FRR ≤1%
Operating Temperature
-20°C to 55°C (-4°F to 131°F)
Operating Humidity
< 90%RH Storage Temperature -25°C to 65°C (-13°F to 149°F) Storage Humidity < 90% Dimension 319.5mm*120mm*51 mm (12.58in*4.72in*2 in) (H*L*D) Facial Recognition Speed ≤ 0.5s Facial Recognition Distance 0.5m to 3m Power Supply DC 12V, 3A / IEEE 802.3af/at Software ZKBio Time (Only Time & Attendance Firmware) ZKBioSecurity (Only Access Control Firmware)
