Display
7-inch Touch Screen
User Capacity
10,000
Face Capacity
10,000
Transaction Capacity
200,000
Standard Functions
ADMS, T9 Input, DST, Camera, 9-digit User ID, Access Levels, Groups, Holidays, Anti-passback, Record Query, Tamper Switch Alarm, Multiple Verification Methods
Hardware
Quad-core ARM Cortex-A7@ 1.2GHz, 1GB RAM / 8GB Flash, 2MP WDR Low Light Camera, Adjustable LED Light Brightness
Communication
TCP/IP, Wiegand Input / Output, Wi-Fi, RS485 / RS232
Access Control Interface
3rd-Party Electric Lock, Door Sensor, Exit Button, Alarm output, Auxiliary Input
Biometrics Algorithm
ZKLiveFace V5.9
Operating Humidity
0% to 90%
Operating Temperature
-20°C to 45°C (-4°F to 113°F)
Dimension
119.9 * 226.6 * 27.7 (mm) (W*H*D)
Ingress Protection Rating
IP65
Supported Software
ZKBio Access IVS
