The SF300 is an IP based fingerprint terminal, which operate in both network mode and standalone mode. it can connect with ZKAccess3.5 software for access control and time attendance management. Wiegand output makes SF300 flexible to connect with ZKTeco or any 3rd party controllers as a slave reader, Additionally, wiegand input allows two units of SF300 to configure with each other and utilize Master & Slave solution, which requires user verification at both entrance and exit. Meanwhile, anti-passback function can be used to maximize the security.
LCD
2.8 inch resistive touch screen
Fingerprint Sensor
ZK Optical Sensor (500DPI)
Algorithm Version
ZKFinger V10.0
Communication
TCP/IP, USB Host
Fingerprint Capacity
1,500
Recor Capacity
80,000
Access Control Interface
Electric lock, Door sensor, Alarm, Exit button, Door Bell
Wiegand Signal
Wiegand input & output
Aux. Input
1ea for linkage function
Power Supply
DC 12V / 3A
Operating Temperature
0 ~ 45°C (32° ~ 113°F)
Operating Humidity
20 ~ 80%
Dimension
105 x 105 x 34mm (L*W*H)
