Native resolution
4K UHD 3840 x 2160 (16:9)

Backlight
Edge-lit LED

LED lifespan
50,000 hours to 50% brightness

Display orientation
Landscape

Pixel pitch (WxH)
0.372 x 0.372mm

Bezel size (bottom/side/top)
13mm/10mm/10mm

Brightness (typical) – (cd/sq m)
500 nits

Contrast ratio (typical)
1,200:1

Viewing angle (CR 10:1)
178 degrees h/v

Refresh rate
60Hz

Response time (typical)
8ms

Color space typical (CIE 1931)
75%

Display colors
10 bit, 1.07 billion

Video inputs
4 x HDMI (Ver 2.0 HDCP 2.2)
DisplayPort (Ver 1.2a, HDCP 1.3)
VGA
OPS
2 x USB 2.0
USB C

Video outputs
DisplayPort 1.2a
HDMI 2.0

Audio inputs
RCA (L/R) line in

Audio outputs
3.55mm headphone jack
Optical Audio Out

Control inputs
RS 232 (D-Sub9)
LAN (RJ45)
IR wire extender

Power input rating
100-240 VAC @ 50-60Hz

Power consumption
73W typical without OPS
140W maximum without OPS
≤0.5W in standby without OPS

Operating temperature
32-104°F (0-40°C)

Storage temperature
-4-140°F (-20-60°C)

Operating humidity
20-90% RH non-condensing

Size (Panel only)
(WxHxD) 57.3 x 32.8 x 2.8” (1455 x 834 x 71mm)

Weight
54.5lbs (24.7kg)

Mounting
VESA 600 x 400mm, M6

Runtime
Designed for 16/7 operation featuring a reliable power supply*

Features
Commercial LCD with LED backlight
HDR10 support
Auto source switching
Video wall mode
low latency video processing option
Wake on LAN
On/off scheduling
2 x 10W built-in speakers
OPS module slot
On/Off Scheduler
USB media playback of Photo / Video /MP3
HDMI-CEC
Failover auto source switching
Kensington lock
Wi-Fi and Miracast device connectivity
Pixel Shifting

Accessories
Panel ships with IR remote control
External IR receiver
Power cable
User manual
Optional WiFi Module

Brand

Christie

Shopping cart

Christie LCD Panel Access II Series 4K UHD LCD panels UHD652-L
