Christie LCD Panel Secure Series II TAA-compliant panels SUHD553-L

55” 4K UHD 500 nit LCD panel designed for secure operation.

Share:

Native resolution
4K UHD 3840 x 2160 (16:9)

Backlight
Edge-lit LED

LED lifespan
50,000 hours to 50% brightness

Display orientation
Landscape

Pixel pitch (WxH)
0.315 x 0.315mm

Bezel size (bottom/side/top)
15mm/12mm/12mm

Brightness (typical) – (cd/sq m)
500 nits

Contrast ratio (typical)
5,000:1

Viewing angle (CR 10:1)
178 degrees h/v

Refresh rate
60Hz

Response time (typical)
8ms

Color space typical (CIE 1931)
68%

Display colors
10 bit, 1.07 billion

Video inputs
4 x HDMI (Ver 2.0b, HDCP 2.2)
DisplayPort Ver 1.2
OPS

Audio outputs
3.5mm headphone jack

Control inputs
RS-232 via D-Sub9
LAN via RJ45
IR wire extender
USB-A2.0 for service

​​Power input rating
100-240 VAC @ 50/60Hz

Power consumption
TBD without OPS
230W maximum without OPS
<=0.5W standby without OPS Operating temperature 32-104°F (0-40°C) Storage temperature -4-140°F (-20-60°C) Operating humidity 20-90% RH non-condensing ​Physical size (panel only) 48.7 x 28.0 x 2.8" (wxhxd) - (1238.5 x 712 x 77 mm) Weight 58 lbs (26.3kg) Mounting VESA 300 x 300mm, M6 Runtime Recommended for 18/7 operation featuring a reliable power supply* Features Commercial-grade LCD with LED backlight OPS slot Anti-glare treatment 2 x 15W speakers HDMI-CEC DICOM simulation HDR10 compatible Priority Input Source Source switching for failover No RF capability 4 window multi-source UHD viewing (Quadview, PiP, PBP) MEMC Crestron Connected 2 Accessories Panel ships with HDMI 2.0 Cable, RS232 Cable, Remote Control with batteries, IR receiver

Brand

Christie
