The D-Link DES-1018P 16-Port Unmanaged Desktop Fast Ethernet PoE Switch with 2x Combo Gigabit/SFP Uplinks enables users to easily connect and supply power to PoE-capable devices such as wireless access points (APs), network cameras and IP phones. This D-Link DES-1018P 16-Port Unmanaged Desktop Fast Ethernet PoE Switch can also connect other Ethernet devices like computers, printers and network attached storage (NAS) to fit into any type of network application.
Sixteen (16) 10/100 Fast Ethernet RJ45 ports Auto MDI/MDIX crossover.
Eight (8) Power over Ethernet (PoE) ports, total budget 80W.
Two (2) 10/100/1000 Gigabit combo uplink ports.
Allows for flexible installation for wireless access points.
Enhanced surge protection on all PoE ports*.
1.6 Gbps switching fabric and IEEE 802.3x flow control.
Plug and play installation.
IEEE 802.3az Energy Efficient Ethernet.
Power Over Ethernet IEEE 802.3af
This D-Link DES-1018P 16-Port Unmanaged Desktop Fast Ethernet PoE Switch features 8 ports that support the IEEE 802.3af PoE protocol. Each of the PoE ports can supply up to 15.4 watts, with a total PoE budget of 80 watts, allowing users to attach an IEEE 802.3af-compliant device to this DES-1018P without requiring additional power. PoE is especially suitable for devices that are far from power outlets or when users want to minimise the clutter of extra cables as power is supplied via the Ethernet cables themselves.
Expand Your Network
The addition of 2 Gigabit combo uplink ports means businesses can increase their network bandwidth via wired speed while offering redundancy so voice and surveillance data are transferred reliably. The combo design can increase bandwidth by offering two Gigabit copper or fibre connections, giving administrators more options for expansion.
Cut Your Energy Costs
To help small businesses save on operating costs, this D-Link DES-1018P 16-Port Unmanaged Desktop Fast Ethernet PoE Switch supports IEEE 802.3az Energy Efficient Ethernet (EEE). This feature senses network traffic to automatically put ports that are not being used to sleep and also powers them on as required.**
This D-Link DES-1018P 16-Port Unmanaged Desktop Fast Ethernet PoE Switch is a plug and play device that requires no configuration, so setup is simple and hassle-free. Simply connect the switch to a network to connect multiple computers, share files and make VoIP calls. Support for Auto MDI/MDI-X on all ports eliminates the need for crossover cables when connecting to another switch or hub.
Auto-Negotiation on each port senses the link speed of a network device (either 10 or 100) and intelligently adjusts for compatibility and optimal performance. Combining the convenience of PoE, fast performance, reliability, and ease of use, the 16-Port Fast Ethernet PoE Switch with 2 Gigabit Uplink Ports is the ideal choice for adding PoE devices to a network.
*Surge protection function available for PoE ports only. **Energy savings from IEEE 802.3az Energy Efficient Ethernet (EEE) are dependent on actual usage scenarios.
