D-Link DPH 120SE

INTERNET PHONE MADE FOR HOME & OFFICE

The DPH-120SE Broadband Internet IP Phone allows you to take advantage of your DSL/cable modem connection to make inexpensive Internet phone calls. It combines the industry’s latest Voice over the IP network (VoIP) technology with advanced communication features, and is compatible with industry- wide phone services. This sleek designed IP phone gives you the advantages of VoIP, while retaining the same look and feel of a traditional desktop telephone.

SUPERIOR VOICE QUALITY

The DPH-120SE IP phone incorporates Quality of Service (QoS) to ensure that voice received through the Internet is the same as or even surpasses that received on the ordinary phone. It supports many useful functions such as call transfer, caller ID display, 3-way conference and speed dialing to make it convenient to dial out or answer phone calls.

NETWORK INTERFACE
  • DPH-120SE: 2 10/100BASE-TX Ethernet Ports (1 to PoE
  • LAN switch with 802.3af compliance, 1 to PC)
SIGNAL, MEDIA & NETWORK PROTOCOLS
  • SIP RFC 3261 & the related RFC standard in Appendix A
  • SDP RFC 2327
  • RTP RFC 1889
  • IP assignment: Static IP, DHCP and PPPoE
  • STUN, static port mapping (for NAT traversal)
  • SNTP
  • DNS & DNS SRV
  • TFTP/FTP/HTTP for Auto Provision
  • IP/TCP/UDP/ARP/ICMP
VOICE CODEC
  • G.711a/u (64k bps)
  • G.729A/B (8k bps)
  • G.723.1high/low
  • G.726-32
  • G.722
ADVANCED VOICE QUALITY FEATURES
  • Silence Suppression
  • Acoustic Echo Cancellation (G.167)
  • Voice Active Detection (VAD)
  • Comfort Noise Generation
  • Jitter Buffer
  • DTMF Transmitter (SIP info,Transparent, RFC 2833)
  • Packet Lost Concealment (PLC)
KEYPAD
  • Menu
  • Phone Book
  • Callers
  • 2 Navigator Keys for navigating in configuration; volume adjustment of Ringer, Speaker phone & Handset
  • MWI
  • Conference
  • RLS(Release key)
  • Mute
  • Transfer
  • R/Send (Redial and the entry to access call history; finish dialing and call the number)
  • Hold
  • Speaker
  • 12 numeric keys with star & pound key
CALL FEATURES
  • Call Forward (Busy, No answer,
  • Unconditional)
  • Call Waiting
  • Call waiting Indication
  • Three Way Conference
  • Anonymous Call/Rejection
  • Message Waiting Indication
  • Do Not Disturb
  • Auto Answer
  • Black list
  • Limit list
  • Auto hangup
  • Ban outgoing
  • hotline
SPEAKER PHONE
  • Built-in Speaker
REMOTE FIRMWARE UPGRADE
  • FTP/TFTP/HTTP for Firmware remote update
  • APS auto-provisioning for firmware and profile upgrade
USER INTERFACE/NETWORK MANAGEMENT
  • Large dot matrix LCD display
  • HTTP(WEB) UI in English version & other Languages
  • QoS
  • IEEE 802.1p Compliant
  • Diffserv (DSCP)/ToS
  • SECURITY/ CLASS OF SERVICE
  • 802.1Q VLAN Tag
  • Full range VLAN ID Support
PHONE FEATURES
  • 1 SIP user
  • Caller ID display
  • Call History: 100 Missed Calls, 100 Received Calls, 100 Dialed Calls
  • Phone book (up to 500 contact names and phone numbers)
  • Supports XML Phonebook/Browser
  • Supports click to dial via web phonebook
  • Day/Time display
  • Call/Time display
  • 14 Selective Ring tones (9 tones & 5 melodies)
  • 10 Speed dial number
  • Incoming call indicator
  • Password control for Configuration
  • Pre-dial before sending
  • Memo
