Dell PowerEdge R640 Rack Server

Categories: , .

Dell PowerEdge R640 Rack Server

Dell PowerEdge R640 Rack Server
Data center evolution starts with modern platforms that easily scale and are optimized for application performance. The PowerEdge R640 is built upon a scalable system architecture and provides the choice and flexibility to easily meet performance demands.



Description
Tech Specs & Customization
Processor
Up to two 2nd Generation Intel® Xeon® Scalable processors, up to 28 cores per processor

Operating System
Canonical® Ubuntu® LTS
Citrix® XenServer®
Microsoft Windows Server® with Hyper-V
Red Hat® Enterprise Linux
SUSE® Linux Enterprise Server
VMware® ESXi

Chassis
Optional LCD or Security bezel

Data Protection
TPM 1.2/2.0 optional Cryptographically signed firmware
Secure Boot
System Lockdown
Secure erase

Dimensions & Weight
Form factor:
Rack (1U)

Chassis Max depth (with bezel):
757.75 mm – For the 8 x 2.5” front bay drive configuration.
808.51 mm – For the 4 x 3.5” or 10 x 2.5” front bay drive configurations (plus up to 2 rear drives).

Drive Bays
Front drive bays:
Up to 10 x 2.5” with up to 8 NVMe, SAS/SATA/SSD/NVMe, max 76.8TB , or up to 10 NVMe drives max 64TB. Or Up to 4 x 3.5” SAS/SATA, max 56TB

Rear drive bays:
Up to 2 x 2.5” SAS/SATA/SSD/NVMe, max 15.36TB

GPU

Accelerators
Up to 1 single-width FPGA or up to 1 single-width GPU

Memory*
24 DDR4 DIMM slots, Supports RDIMM /LRDIMM, speeds up to 2993MT/s, 3TB max
Up to 12 NVDIMM, 192 GB Max
Supports registered ECC DDR4 DIMMs only

Management
Embedded / At-the-Server
iDRAC9 with Lifecycle Controller (Express, Enterprise)
iDRAC Direct
iDRAC REST API with Redfish
Quick Sync 2 BLE/wireless module

Consoles
OpenManage Enterprise
OpenManage Essentials
OpenManage Power Center

Mobility
OpenManage Mobile

Tools
iDRAC Service Module
OpenManage Server Administrator
OpenManage Storage Services
Dell EMC Repository Manager
Dell EMC System Update
Dell EMC Server Update Utility
Dell EMC Update Catalogs

OpenManage Integrations
Microsoft® System Center
VMware® vCenter™
BMC software (available from BMC)

OpenManage Connections
Nagios Core and Nagios XI
HPE Operations Manager i (OMi)
IBM Tivoli® Netcool/OMNIbus
IBM Tivoli® Network Manager IP Edition

Ports
Network daughter card options:
4 x 1GE or 2 x 10GE + 2 x 1GE or 4 x 10GE or 2 x 25GE

Front ports:
Video, 1 x USB 2.0, available USB 3.0, dedicated IDRAC Direct USB

Rear ports:
Video, serial, 2 x USB 3.0, dedicated iDRAC network port

Video card:
VGA, NVIDIA NVS310 available as PCIe card Up to 3 x Gen3 slots, all x16

Power
Titanium 750W, Platinum 495W, 750W, 1100W, and 1600W
48VDC 1100W, 380HVDC 1100W, 240HVDC 750W
Hot plug power supplies with full redundancy option Up to 8 hot plugs fans with full redundancy

Storage Controllers
Internal controllers:
PERC H330, H730P, H740P, Software RAID (SWRAID) S140

Boot Optimized Storage Subsystem:
HWRAID 2 x M.2 SSDs 240GB or 480GB

External PERC (RAID):
H840

12Gbps SAS HBAs (non-RAID):
External- 12Gbps SAS HBA (non-RAID)
Internal- HBA330 (non-RAID)

Uncompromising performance and density for data center productivity and scale
The poweredge R640 is the ideal dual-socket platform for dense scale-out data center computing and storage. Benefit from the flexibilty of 2.5” or 3.5” drives, the performance of NVMe and embedded intelligence to ensure optimized application performance in a secure platform. With embedded diagnostics and SupportAssist, the R640 delivers maximum uptime in a worry-free environment.

Ideal workloads:

Dense software-defined storage
Service providers: application tier
Dense private cloud
Virtualization
HPC
