Dell Server PowerEdge R930 Rack

Categories: , .

Dell Server PowerEdge R930 Rack

Scalability to maximize performance.
Accelerate enterprise applications with Dell’s most powerful server featuring highly scalable processing, memory and internal storage.

Built for scalability and speed
Maximize the performance of your most demanding enterprise applications, including CRM, ERP, OLTP and in-memory databases. The PowerEdge R930 flexibly scales to optimize transactions and operations and can significantly reduce latency. Leveraging the latest Intel® Xeon® processor E7 v4 product family (up to 24 cores per processor), the 4-socket R930 can scale to meet virtually any challenge.

Utilize all 96 processing cores to access up to 6TB DDR4 memory on 96 DIMMs.
Optimize performance across compute, memory and I/O with up to eight PCIe SSDs.
Protect mission-critical and data-intensive applications with Intel E7 RAS features.

Simplicity through automation
Efficiently manage Dell servers in physical, virtual, local and remote environments with PowerEdge embedded server intelligence — integrated Dell Remote Access Controller (iDRAC8) with Lifecycle Controller and OpenManage Essentials. OpenManage automates the most frequently performed server management tasks agent-free – including deployment, updates, monitoring and maintenance – regardless of the installed OS or hypervisor.

Reduce setup time by up to 99 percent with zero touch automated deployment.
Cut up to 92 percent of time spent updating servers according to your policies.
Leverage the same OpenManage Integration benefits with your existing VMware®, Microsoft or BMC Software consoles.



Processor
Intel® Xeon® Processor E7-8800 Product Family
Intel® Xeon® Processor E7-4800 Product Family
Operating System
Microsoft® Windows Server® 2008 R2
Microsoft Windows Server 2012
Microsoft Windows Server 2012 R2
Microsoft® Windows Server® 2016
Novell® SUSE® Linux Enterprise Server
Red Hat® Enterprise Linux
VMware® ESX®
Memory3
(96 DIMMS): 8GB/16GB/32GB/64GB/128GB RDIMM, LRDIMM up to 2400 MT/s
Drive Bays
Up to 24 x 2.5” hot-plug 12Gb/6Gb SAS HDD or SAS/SATA SSD
Up to 8 front-accessible Express Flash NVMe PCIe SSD (PCIe 3.0)
Dimensions & Weight
H: 6.8” (172.6mm)
W: 18.99” (482.4mm)
D: 31.59” (802.3mm) with PSU and bezel
D: 31.01” (787.7mm) with PSU and without bezel
Chassis
4U
Availability
Hot-plug hard drives, hot-plug redundant power, hot-plug redundant fans, ECC memory, internal dual SD module
Power
Hot-plug redundant PSUs: 750W AC, 1100W AC
RAID Controllers
Internal controllers: PERC H330, PERC H730P
External HBAs (RAID): PERC H830
External HBAs (non-RAID): 12Gbps SAS HBA
Chipset
Intel® C602J
Storage
2.5” SATA/SAS SSD, SAS HDD (15K, 10K), nearline SAS HDD (7.2K)
2.5” Dell PowerEdge NVMe Express Flash PCIe SSD
Slots
Up to 10 PCIe 3.0 slots
1 RAID slot
1 NDC slot
Management
iDRAC8 with Lifecycle Controller
iDRAC8 Express (default)
iDRAC8 Enterprise (upgrade option)
8GB or 16GB vFlash media (upgrade options)
IPMI 2.0 compliant
Dell OpenManage Essentials
Dell OpenManage Mobile
Dell OpenManage Power Center

Dell OpenManage Integrations:
Dell OpenManage Integration Suite for Microsoft System Center
Dell OpenManage Integration for VMware® vCenter

Dell OpenManage Connections:
HP Operations Manager, IBM Tivoli® Netcool®, and CA Network and Systems Management
Dell OpenManage Plug-in for Oracle Database Manager
Communications
Embedded NICs:
Broadcom® 5720 quad-port 1Gb NDC
Broadcom® 57800 2x10Gb DA/SFP+ + 2x1Gb BT NDC
Broadcom® 57800 2x10Gb BT + 2x1Gb BT NDC
Broadcom® 57840S quad-port 10Gb SFP+ Direct Attach Rack NDC
Intel® I350 quad-port 1GbE NDC
Intel® X520 dual-port 10Gb DA/SFP+, + I350 DP 1GbE, NDC
Intel® X540 10GbE BT dual-port + I350 1Gb BT DP NDC
Rack Support
ReadyRails® II, the sliding rail system for the R930, provides tool-less support for 4-post racks with square or unthreaded round mounting holes, including all generations of Dell racks. The sliding rail system also supports tooled mounting in 4-post threaded racks
Video Card
Matrox® G200 with 8MB memory
