Samsung SNP-6320RH

Samsung SNP-6320RH

2MP Full HD 32x Network IR PTZ Dome Camera
The SNP-6320RH features a 32x optical zoom lens and IR viewable length up to 493ft enabling users to capture Full HD high quality images anytime, anywhere. With endless 360° pan rotation and 190° tilt control, advanced Auto Tracking functions are suitable to make your monitoring more powerful. Power is supplied by 24v AC to accomodate powerful IR illuminators & ultra-low temperature operations.

Imaging Device 1/2.8" 2.38M CMOS
Total/ Eective Pixels 1,952(H) x 1,116(V), 2.18M pixels/ 1,944(H) x 1,104(V), 2.14M pixels
Scanning System Progressive
Min. Illumination
Color : 0.3Lux (1/30sec, F1.6, 50IRE), 0.005Lux (2sec, F1.6, 50IRE)
0.1Lux (1/30sec, F1.6, 30IRE), 0.0005Lux (2sec, F1.6, 30IRE)
B/W : 0Lux (IR LED on)
S / N Ratio 50dB
Video Output CVBS : 1.0 Vpp / 75Ω composite, 720 x 480(N), 720 x 576(P), for installation
Focal Length (Zoom Ratio) 4.4 ~ 140.8mm (Optical 32x)
Max. Aperture Ratio F1.6(Wide) / F4.9(Tele)
Angular Field ofView H : 63.68˚(Wide) ~ 2.24˚(Tele) / V : 37.52˚(Wide) ~ 1.28˚(Tele)
Min. Object Distance 1.5m (4.92ft)
Focus Control AF / One-shot AF / Manual
Lens/ Mount Type DC auto iris(IR corrected) / Board-in type
Pan / Tilt Range 360˚ Endless/ 190˚ (-5˚ ~185˚ )
Pan / Tilt Speed Preset : 250˚/sec, Manual : 0.024˚/sec ~ 120˚/sec
Sequence / Preset Accuracy Preset (255ea), Swing, Group (6ea), Trace, Tour, Auto run, Schedule / ±0.2˚
Azimuth Yes(E / W / S / N / NE / SE / NW / SW OSD)
AutoTracking O / On
IR LED 2ea
Viewable Length 150m (492.13ft)
Camera Title O / On (Displayed up to 15 characters)
Day & Night Auto (ICR)/ Color / B/W
Backlight Compensation O / BLC / HLC / WDR
Wide Dynamic Range 120dB
Contrast Enhancement SSDR (O / On)
Digital Noise Reduction SSNRIII (2D+3D noise lter) (O / On)
Digital Image Stabilization O / On
Defog O / Auto / Manual
Motion Detection O / On (4ea, Rectanglular zones)
Privacy Masking O / On (32ea, Rectanglular zones)
- Color : Grey / Green / Red / Blue / Black / White, - Zoom ratio option for mask mode
Gain Control O / Low / Medium / High / Manual
White Balance ATW / AWC / Manual / Indoor/ Outdoor / Mercury / Sodium
Electronic Shutter Speed Minimum / Maximum / Anti icker (2 ~ 1/12,000sec)
Digital Zoom 16x, area zoom funtion support digital zoom 2x
Flip / Mirror O / On
IntelligentVideo Analytics Tampering (Scene change), Virtual line, Enter/ Exit, (Dis)Appear,
Audio detection, Face detection
Alarm I/O Input 4ea / Output 3ea (Relay type)
Remote Control Interface RS-485/422
RS-485 Protocol Samsung-T/E, Pelco-P/D, Panasonic, Honeywell, AD, Vicon, Bosch, GE
AlarmTriggers Alarm input, Motion detection, Intelligent video analytics, Network disconnect
Alarm Events File upload via FTP and E-mail, Notication via E-mail, Localstorage (SD/SDHC) or NAS recording at Network disconnected, External output, PTZ preset
Ethernet RJ-45 (10/100BASE-T)
Video Compression Format H.264 (MPEG-4 Part 10/AVC) : Main / Baseline / High, MJPEG
Resolution 1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768,
800 x 600, 720 x 576, 640 x 480, 640 x 360, 320 x 240, 320 x 180
Max. Framerate
H.264 : Max. 60fps at all resolutions
MJPEG : 1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768 : Max. 15fps
800 x 600, 720 x 576, 640 x 480, 640 x 360, 320 x 240, 320 x 180 : Max. 30fps
Smart Codec Manual mode (Area-based : 5ea), Face detection mode
VideoQuality Adjustment H.264 : Compression level, Target bitrate level control, MJPEG : Quality level control
Bitrate Control Method H.264 : CBR or VBR, MJPEG : VBR
Streaming Capability Multiple streaming (Up to 10 proles)
Audio In Selectable (Mic in / Line in), Supply voltage : 2.5V DC (4mA), Input impedance : approx. 2K Ohm
Audio Out Line out (3.5mm stereo mini jack), Max output level : 1 Vrms
Audio Compression Format G.711 u-law/G.726 selectable, G.726 (ADPCM) 8KHz,
G.711 8KHz, G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps
Audio Communication Bi-directional audio (2-way)
IP IPv4, IPv6
HTTPS(SSL) login authentication, Digest login authentication
IP address ltering, User accesslog, 802.1x authentication (EAP-TLS, EAP-LEAP)
Streaming Method Unicast/ Multicast
Max. User Access 15 users at unicast mode
Edge Storage
SD/SDHC/SDXC (Up to 128G)
Motion imagesrecorded in the SD/SDHC/SDXC memory card can be downloaded
NAS (Network Attached Storage), Local PC for instant recording
Application Programming Interface ONVIF prole S, SUNAPI (HTTP API), SVNP 1.2, Wisenet Open Platform
Webpage Language English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Danish,
Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek, Finnish, Norwegian
Supported OS : Windows XP / VISTA / 7 / 8, MAC OS X 10.7
Supported Browser : Microsoft Internet Explorer (Ver.8 ~ 11), Mozilla Firefox (Ver. 9 ~ 19),
Google Chrome (Ver. 15 ~ 25), Apple Safari (Ver. 6.0.2(Mac OS X 10.8, 10.7 only), 5.1.7)
* Mac OS X only
Central Management Software SmartViewer, SSM
OperatingTemperature / Humidity -50°C ~ +55°C (-58°F ~ +131°F)/ Lessthan 90% RH
Storage Temperature / Humidity -30°C ~ +60°C (-22°F ~ +140°F)/ Lessthan 90% RH
Ingress Protection /Vandal Resistance IP66 / IK10
InputVoltage / Current 24V AC only / 6A
Power Consumption Max. 30W (Heater o)/ Max. 35W/90W (Heater o/on, IR on)
