Samsung SNV-L6014RM

Samsung SNV-L6014RM

SNV-L6014RMSNV-L6014RM
2MP Full HD Vandal-Resistant Network IR Flat Dome
The SNV-L6014RM mobile network camera has a range of features with 2 megapixel 1080p high definition images with a 3.6mm fixed lens, and 15 meter IR LEDs. Hallway View mode optimizes the image for portrait orientation, and also includes a built-in microphone. The SNV-L6014RM has a M12 connector for secure installation in transportation applications and its vibration resistant build (EN50155, EN50121) ensures reliable video in any transportation environment. Rated to IP66/IK10, it can work effectively in more demanding environments that are prone to severe or varying weather conditions as well as tampering or physical attack.

VIDEO
Imaging Device 1/2.9" 2.19M CMOS
Total Pixels 2,000(H) x 1,121(V)
Eective Pixels 1,984(H) x 1,105(V)
Scanning System Progressive
Min. Illumination Color : 0.15Lux (1/30sec, F1.8), 0.003Lux (2sec, F1.8)
B/W : 0Lux (IR LED on)
LENS
Focal Length (Zoom Ratio) 3.6mm xed
Max. Aperture Ratio F1.8
Angular Field ofView H : 86.5°/ V : 47.8° / D : 101.2°
Min. Object Distance 0.5m (1.64ft)
Lens Type Fixed
Mount Type Board type
PAN / TILT / ROTATE
Pan / Tilt/ Rotate Range -5° ~ 5° / 0° ~ 67° / 90°
OPERATIONAL
IRViewable Length 15m (49.21ft)
Camera Title O / On (Displayed up to 15 characters)
Day & Night True Day & Night
Backlight Compensation O / BLC
Contrast Enhancement SSDR (Samsung Super Dynamic Range) (O / On)
Digital Noise Reduction SSNR (O / On)
Motion Detection O / On (4ea rectangular zones)
Privacy Masking O / On (6ea rectangular zones)
Gain Control O / Low / Middle / High
White Balance ATW / AWC / Manual / Indoor / Outdoor
LDC (Lens Distortion Correction) O / On (5 levels with min / max)
Electronic Shutter Speed Minimum / Maximum / Anti icker
Flip / Mirror Flip / Mirror/ Hallway view
IntelligentVideo Analytics Motion detection with metadata, Tampering
AlarmTriggers Motion detection, Tampering detection, SD card error, NAS error
Alarm Events File upload via FTP and E-mail, Localstorage recording at event, Notication via E-mail
NETWORK
Ethernet M12 connector (10/100BASE-T)
Video Compression Format H.264, MJPEG
Resolution 1920 x 1080, 1280 x 960, 1280 x 720, 1024 x 768,
800 x 600, 720 x 576, 640 x 480, 320 x 240
Max. Framerate
H.264 : Max. 30fps at all resolutions
MJPEG : Max. 1fps at 1920 x 1080, 1280 x 960, 1280 x 720, 1024 x 768,
Max. 15fps at other resolution
VideoQuality Adjustment H.264 : Target bitrate level control, MJPEG : Quality level control
Bitrate Control Method H.264 : CBR or VBR, MJPEG : VBR
Streaming Capability Multiple streaming (Up to 3 proles)
Audio I/O Line-in, Line-out, Built-in mic
Audio Compression Format G.711 u-law / G.726 selectable
G.726 (ADPCM) 8KHz, G.711 8KHz, G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps
Audio Communication Bi-directional audio
IP IPv4, IPv6
Protocol TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP,
SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour
Security
HTTPS(SSL) login authentication, Digest login authentication
IP address ltering, User accesslog, 802.1x authentication
Streaming Method Unicast/ Multicast
Max. User Access 6 users at unicast mode
Storage
micro SD/SDHC max. 32G, NAS - Motion imagesrecorded in the SD memory card can be downloaded - Manual recording at local PC
Application Programming Interface ONVIF Prole S, G, SUNAPI (HTTP API)
Webpage Language
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese,
Swedish, Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch,
Croatian, Hungarian, Greek, Norwegian, Finnish
WebViewer Supported OS : Windows 7, 8, 10, Mac OS X 10.8, 10.9, 10.10, 10.11
Supported Browser : Explore 11, Mozilla Firefox 43, Apple Safari 9 * Mac OS X only
Central Management Software SmartViewer
ENVIRONMENTAL
OperatingTemperature / Humidity
-30°C ~ +55°C (-22°F ~ +131°F)/ Lessthan 90% RH
* Start up should be done at above -20°C (-4°F)
Storage Temperature / Humidity -30°C ~ +60°C (-22°F ~ +140°F) / Lessthan 90% RH
Ingress Protection IP66
Vibration Resistance
EN55011:2009+A1:2010, EN50581:2012, EN50121-3-2:2015, EN61000-4-2:2009,
EN61000-4-3:2006+A2:2010, EN61000-4.4:2012, EN61000-4-5:2014,
EN61000-4-6:2009, EN50155:2007, NEMA 4x
Vandal Resistance IK10
ELECTRICAL
InputVoltage / Current PoE (IEEE802.3af, Class2)
Power Consumption Max. 5.8W
MECHANICAL
Color/ Material Ivory / Metal
Dimensions(WxH) 99.0 x 52.0 x 100.0mm (3.9" x 2.05" x 3.94")
