Samsung XNP-6040H

Samsung XNP-6040H

XNP-6040HXNP-6040H
2MP Outdoor Micro PTZ
Wisenet X powered by Wisenet 5 network outdoor PTZ camera, 2MP, full HD(1080p) @ 60fps WDR off/on(120dB) or @30fps WDR on(150dB), 4.3x optical zoom lens (2.8mm ~12mm) (119.5º ~ 27.9º), pan: 0°~350°, Tilt: 0°~ 90°, H.265/H.264/MJPEG, WiseStream II compression technology, 150dB WDR, USB port for easy installation, advanced video analytics and sound classification, true D/N, dual SD card, HLC, Defog detection, DIS , 12VDC/PoE, IP66, IK10, -22°F ~ 131°F

VIDEO
Imaging Device 1/2.8" 2.16M CMOS
Total Pixels 1,945(H) x 1,109(V), 2.16M
Eective Pixels 1,945(H) x 1,097(V), 2.13M
Scanning System Progressive Min. Illumination Color : 0.015 Lux (1/30sec, F1.4), B/W : 0.0015 Lux (1/30sec, F1.4)
S / N Ratio 50dB
VideoOut CVBS : 1.0 Vpp / 75Ω composite, 720 x 480(N), 720 x 576(P), for Installation
USB : Micro USB Type B, 1280 x 720 for Installation
LENS
Focal Length (Zoom Ratio) 2.8 ~ 12mm (Optical 4.3x)
Max. Aperture Ratio F1.4
Angular Field ofView H : 119.5˚ ~ 27.9˚, V : 62.8˚ ~ 15.7˚, D : 142.1˚ ~ 32.0˚
Min.Object Distance 1.5m (4.92ft) (Wide), 2m (6.56ft) (Tele)
Focus Control Auto / Manual/ One Push
Lens/ Mount Type DC Auto Iris/ Board-in type
PAN/TILT/ROTATE
Pan Range / Speed 0˚ ~ 350˚ / 0.1˚/sec ~60˚/sec
Tilt Range / Speed 0˚ ~ 90˚ / 0.1˚/sec ~ 60˚/sec
Sequence / Preset Accuracy Preset (300ea), Swing, Group (6ea), Trace, Tour (1ea), Auto Run, Schedule / ± 0.5˚
Azimuth Yes(E / W / S / N / NE / NW / SE / SW)
AutoTracking Support OPERATIONAL
Camera Title
O / On (Displayed up to 85 Characters) - W/W : English / Numeric / Special Characters - China : English / Numeric / Special/ Chinese Characters - Common : Multi-line (Max. 5), Color (Gray / Green / Red / Blue / Black / White), Transparency, Auto scale by Resolution
Day & Night Auto (ICR)/ Color/ B/W
Backlight Compensation O / BLC / HLC / WDR
Wide Dynamic Range 150dB
Contrast Enhancement SSDR (O / On)
Digital Noise Reduction SSNRV (2D + 3D Noise lter) (O / On)
Digital Image Stabilization O / On (Built-in Gyro sensor)
Defog O / Auto / Manual
Motion Detection O / On (8ea, 8point Polygonal zones)
Privacy Masking
O / On (24ea, Rectangle zones) - Color : Gray / Green / Red / Blue / Black / White - Zoom ratio option for mask mode - Mosaic
Gain Control O / Low / Middle / High
White Balance ATW / AWC / Manual / Indoor/ Outdoor (included Mercury & Sodium)
Electronic Shutter Speed Minimum / Maximum / Anti icker (2 ~ 1/12,000sec)
Digital Zoom 24x, area zoom function support digital zoom 2x
Flip / Mirror O / On
Video & Audio Analytics
Tampering, Loitering, Directional detection, Defocus detecion, Fog detection, Virtual line, Enter/Exit, (Dis) Appear, Audio detection, Face detection, Motion detection, Digital auto tracking, Sound classication
Serial Interface RS-485 - Samsung-T/E, Pelco-D/P, Panasonic, Bosch, AD, GE, Vicon, Honeywell
Alarm I/O Input 1ea / Output 1ea
AlarmTriggers Motion detection, Tampering, Audio detection, Face detecton, Video analytics, Alarm input, Network disconnection
Alarm Events File upload Via FTP, E-Mail, Notication Via E-Mail, Localstorage (SD/SDHC/SDXC) or NAS recording at event triggers, External output, preset
Pixel Counter Support NETWORK
Ethernet RJ-45 (10/100 BASE-T)
Video Compression Format H.265 / H.264 (MPEG-4 part 10/AVC) : Main / Baseline / High, MJPEG
Resolution 1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 800 x 448, 720 x 576, 720 x 480, 640 x 480, 640 x 360, 320 x 240
Max. Framerate H.265/H.264 : Max 60fps at all resolutions, MJPEG : Max. 30fps at all resolutions
Smart Codec Manual mode (Area-based : 5ea)
WiseStreamII Support VideoQuality Adjustment H.265 / H.264 / MJPEG : Target Bitrate Level Control
Bitrate Control Method H.265 / H.264 : CBR or VBR, MJPEG : VBR
Streaming Capability Multiple Streaming (Up to 10 Proles)
Audio In Selectable (Mic in / Line in), Supply Voltage : 2.5V DC (4mA), Input Impedance : Approx. 2K Ohm
AudioOut Line out (3.5mm mono jack), Max output level : 1 Vrms
Audio Compression Format G.711 u-law /G.726 Selectable, G.726 (ADPCM) 8KHz, G.711 8KHz G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps, AAC-LC : 48Kbps at 16KHz
Audio Communication Bi-dierctional
IP IPv4, IPv6
Protocol TCP/IP,UDP/IP, RTP (UDP), RTP (TCP), RTCP,RTSP,NTP,HTTP,HTTPS, SSL,DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3 (MIB-2), ARP,DNS,DDNS,QoS, PIM-SM,UPnP, Bonjour
Security HTTPS(SSL) Login Authentication, Digest Login Authentication, IP Address Filtering, User access Log, 802.1X Authentication (EAP-TLS, EAP-LEAP)
Streaming Method Unicast / Multicast
Max. User Access 20 users at Unicast Mode
Edge Storage
SD/SDHC/SDXC 2slot (up to 512 GB) - Continuousrecording (1'stslot to 2'nd slot) - Motion Imagesrecorded in the SD/SDHC/SDXC memory card can be downloaded. NAS (Network Attached Storage), Local PC for Instant Recording
Application Programming Interface ONVIF prole S/G, SUNAPI 2.0 (HTTP API), Wisenet Open Platform
Webpage Language English, French, German, Spanish, Italian, Chinese, Russian, Japanese, Swedish, Portuguese, Turkish, Polish, Czech, Dutch, Hungary, Greek
WebViewer
Supported OS : Windows 7, 8, 10, Mac OS X 10.10, 10.11, 10.12
Non-plugin Webviewer - Supported Browser: Google Chrome, MS Edge, Mozilla Firefox , Apple Safari 10
(Mac OS X only) Plug-in Webviewer - Supported Browser : MS Explore 11, Apple Safari 10 (Mac OS X only)
Central Management Software SmartViewer, SSM
ENVIRONMENTAL
OperatingTemperature / Humidity -30°C ~ +55°C (-22°F ~ +131°F)/ Lessthan 90% RH
Storage Temperature / Humidity -30°C ~ +60°C (-22°F ~ +140°F)/ Lessthan 90% RH
Ingress Protection /Vandal Resistance IP66 / IK10
ELECTRICAL
InputVoltage / Current 12V DC, PoE
Power Consumption Max. 8.6W (12V DC), Max. 9.6W (PoE)
MECHANICAL
Color/ Material Ivory / Aluminum
Dimensions(WxH) Ø136.1 x 106.1mm (Ø5.36" x 4.18")
