Samsung XNV-6081Z

Samsung XNV-6081Z

XNV-6081Z
2MP Vandal-Resistant Outdoor Network Dome PTRZ Camera
The Wisenet X series PLUS powered by Wisenet 5 network outdoor vandal dome camera features a modular structure, 2MP, Full HD(1080p) @ 60fps, motorized vari-focal lens 4.3x (2.8~12mm) (119.5°~27.9°), and PTRZ capability for easy installation. Triple codec H.265/H.264/MJPEG with WiseStream II technology reduces bandwidth and storage requirements. Additional features include 150dB WDR, USB port for easy installation, advanced video analytics, sound classification and business analytics, shock detection, audio playback, true D/N, dual SD card, hallway view, HLC, fog detection, DIS (Gyro), 12VDC/PoE, optional 24VAC, IP67/IP66/IP6K9K, IK10+, NEMA 4X, -50°C ~ +60°C (-58°F ~ +140°F), white color, ivory skin included, optional black skin cover. The modular design allows for easy installation of the camera case separately from the camera module. In addition, the camera module box includes a cutout for easy configuration without disassembling the camera/case.

XNV-6081Z XNV-8081Z
VIDEO
Imaging Device 1/2.8" 2MP CMOS 1/1.8" 6MP CMOS
Effective Pixels 1945(H) x 1097(V) 2616(H) x 1976(V)
Min. Illumination Color : 0.015Lux (F1.4, 1/30sec)
BW : 0.0015Lux (F1.4, 1/30sec)
Color : 0.07Lux (F1.2, 1/30sec)
BW : 0.007Lux (F1.2, 1/30sec)
Video Out USB : Micro USB type B, 1280x720 for installation
LENS
Focal Length (Zoom Ratio) 2.8~12mm(4.3x) motorized varifocal 3.6~9.4mm(2.6x) motorized varifocal
Max. Aperture Ratio F1.4(Wide) ~ F3.6(Tele) F1.2(Wide) ~ F2.4(Tele)
Angular Field of View
H : 119.5°(Wide)~27.9°(Tele)
V : 62.8°(Wide)~15.7°(Tele)
D : 142.1°(Wide)~32.0°(Tele)
H : 102.5°(Wide)~38.7°(Tele)
V : 74.2°(Wide)~29.0°(Tele)
D : 135.5°(Wide)~48.6°(Tele)
Min. Object Distance 0.5m (1.64ft)
Focus Control Simple focus
Lens Type DC auto iris, P-iris
PAN / TILT / ROTATE
Pan / Tilt / Rotate Range Remote adjustment (Max. 200cycles) ±175˚ / 0~85˚ / ±175˚
OPERATIONAL
Camera Title Displayed up to 85 characters
Day & Night Auto (ICR)
Backlight Compensation BLC, HLC, WDR, SSDR
Wide Dynamic Range 150dB 120dB
Digital Noise Reduction SSNR V
Digital Image Stabilization Support
Defog Support
Motion Detection 8ea, 8point polygonal zones
Privacy Masking
32ea, polygonal zones
- Color : Grey/Green/Red/Blue/Black/White
- Mosaic
Gain Control Low / Middle / High
White Balance ATW / AWC / Manual / Indoor / Outdoor
LDC Support
Electronic Shutter Speed Minimum / Maximum / Anti flicker (2~1/12,000sec)
Digital PTZ Support (Preset, Group)
Video Rotation Flip, Mirror, Hallway view (90˚/270˚)
Analytics
Defocus detection, Directional detection, Fog detection, Face detection, Motion detection,
Digital auto tracking, Appear/Disappear, Enter/Exit, Loitering, Tampering, Virtual line,
Audio detection, Sound classification, Shock detection
Business Intelligence People counting, Queue management, Heatmap
Alarm I / O Input 1ea / Output 1ea
Alarm Triggers Analytics, Network disconnect, Alarm input
Alarm Events
File upload via FTP and e-mail
Notification via e-mail
SD/SDHC/SDXC or NAS recording at event triggers
Alarm output
Handover
Audio playback
Audio In Selectable (mic in/line in),
Supply voltage : 2.5VDC (4mA), Input impedance : 2K Ohm
Audio Out Line out, Max. output level : 1Vrms
NETWORK
Ethernet RJ-45 (10/100BASE-T)
Video Compression H.265/H.264 : Main / Baseline / High, MJPEG
