Samsung XNZ-6320

Samsung XNZ-6320

XNZ-6320XNZ-6320
2MP 32x Zoom Box
Wisenet X powered by Wisenet 5 network zoom box camera, 2MP, Full HD(1080p) @60fps, 32X optical zoom lens (4.44mm ~ 142.6mm) (61.8º ~ 2.19º), triple codec H.265/H.264/MJPEG with WiseStream II technology, 150dB WDR, USB port for easy installation, SFP slot, advanced video analytics and sound classification, true D/N, dual SD card, HLC, fog detection, DIS(Gyro), 12VDC/PoE

XNZ-6320
VIDEO
Imaging Device 1/2.8" 2.4M CMOS
Total Pixels 1981(H) x 1288(V), 2.55M
Effective Pixels 1944(H) x 1212(V), 2.35M
Scanning System Progressive scan
Min. Illumination Color : 0.05 Lux (1/30 sec, F1.6)
B/W : 0.005 Lux (1/30 sec, F1.6)
S / N Ratio 50dB
Video Out CVBS : 1.0 Vp-p / 75Ω composite, 720 x 480(N), 720 x 576(P), for installation
USB : Micro USB type B, 1280 x 720, for installation
LENS
Focal Length (Zoom Ratio) 4.44 ~ 142.6mm (Optical 32x)
Max. Aperture Ratio F1.6 (Wide) / F4.4 (Tele)
Angular Field of View H : 61.8˚(Wide) ~ 2.19˚(Tele) / V : 36.2˚(Wide) ~ 1.24˚(Tele)
Min. Object Distance Wide 1.5m (4.92ft), Tele 2m (6.56ft)
Focus Control Auto / Manual / One shot AF
Lens Type DC auto iris
Mount Type Board-in type
OPERATIONAL
Camera Title
Off / On (Displayed up to 85 characters)
- W/W : English / Numeric / Special characters
- China : English / Numeric/Special / Chinese characters
- Common : Multi-line (Max 5), Color (Grey / Green / Red / Blue / Black / White), Transparency,
Auto scale by resolution
Day & Night Auto (ICR) / Color / B/W / Schedule
Backlight Compensation Off / BLC / HLC / WDR
Wide Dynamic Range 150dB
Contrast Enhancement SSDR (On / Off)
Digital Noise Reduction SSNR5 (2D+3D noise filter) (On / Off)
Digital Image Stabilization On / Off (Built-in gyro sensor)
Defog Off / Manual / Auto
Motion Detection On / Off (8ea, Polygonal)
Privacy Masking
On / Off (24 Zones of rectangle zone)
- Color : Grey / Green / Red / Blue / Black / White
- Mosaic
Gain Control Off / Low / Middle / High
White Balance ATW / AWC / Manual / Indoor / Outdoor (Included Mercury & Sodium)
Electronic Shutter Speed Minimum / Maximum / Anti flicker (1 ~ 1 / 12,000sec)
Digital Zoom 32x
Flip / Mirror On / Off
Video & Audio Analytics
Tampering, Loitering, Directional detection, Fog detection, Virtual Line, Enter/Exit,
Appear/Disappear, Audio detection, Face detection, Motion detection, Sound classification,
Shock detection
Serial Interface RS-485/RS-422
- Samsung-T, Pelco-D/P, Panasonic, Bosch, AD, GE, Vicon, Honeywell
Alarm I/O Input 1ea / Output 2ea (Relay)
Alarm Triggers Alarm input, Motion detection, Video & Audio analytics, Network disconnect
Alarm events
File upload via FTP and E-Mail, Notification via E-Mail, TCP and HTTP,
Local storage (SD/SDHC/SDXC) or NAS recording at alarm triggers,
External output, Preset
Audio In Selectable (Mic In/Line In)
Supply voltage: 2.5VDC (4mA), Input impedance: approx. 2K Ohm
Audio out Line out (3.5mm), Max. output level: 1 Vrms
Pixel counter Support
