TP-Link EAP225-Outdoor

Categories: , .

TP-Link EAP225-Outdoor

AC1200 Wireless MU-MIMO Gigabit Indoor/Outdoor Access Point
EAP225-Outdoor

  • Durable, weatherproof enclosure for outdoor Wi-Fi applications
  • Up to 1200Mbps1 with 2×2 MIMO technology
  • Omada Mesh Technology enables wireless connectivity between APs for extended range, making wireless deployments more flexible and convenient
  • Supports Seamless Roaming to smooth the video playbacks and voice calls when moving between locations
  • High transmission power and high gain antennas provide a long-range coverage area
  • Cloud centralized management and Omada app for ultra convenience and easy management
  • Captive portal provides a convenient method for guest authentication
  • Facebook Wi-Fi and SMS authentication help to boost your business
  • 802.3af/Passive PoE (PoE Adapter Included) compatible and simple mounting design allow for flexible deployment and convenient installation
  • HARDWARE FEATURES
    Interface 1x Gigabit Ethernet RJ-45 port
    Button Reset
    Power Supply 802.3af PoE and 24 Passive PoE(PoE injector included)
    Power Consumption 10.5W
    Dimensions ( W x D x H ) 8.5 × 1.8 × 1.1in.
    (215 × 46 × 27 mm)
    Antenna 2.4GHz: 2 × 3dBi
    5GHz: 2 × 4dBi
    Weatherproof Enclosure IP65
    Mounting Pole/Wall mount (mounting kit included)



  • WIRELESS FEATURES
    Wireless Standards IEEE 802.11a/b/g/n/ac
    Frequency 2.4GHz, 5GHz
    Signal Rate 802.11ac: 5G:6.5 Mbps to 867Mbps(MCS0-MCS9,NSS = 1 to 2 VHT20/40/80) 2.4G:78Mbps to 300Mbps (MCS8-MCS9 VHT20/40, NSS=1 to 3)
    802.11n: 6.5 Mbps to 300 Mbps (MCS0-MCS15, VHT 20/40)
    802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
    802.11b: 1, 5.5, 11Mbps
    802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
    Wireless Functions Multiple SSIDs(Up to 16 SSIDs, 8 for each band)
    Enable/Disable Wireless Radio
    Automatic Channel Assignment
    Transmit Power Control (Adjust Transmit Power on dBm)
    QoS(WMM)
    MU-MIMO
    Airtime Fairness
    Beamforming
    Band Steering
    Load Balance
    Rate Limit
    Reboot Schedule
    Wireless Schedule
    Wireless Statistics based on SSID/AP/Client
    Wireless Security Captive Portal Authentication
    Access Control
    Wireless Mac Address Filtering
    Wireless Isolation Between Clients
    SSID to VLAN Mapping
    Rogue AP Detection
    802.1X Support
    Transmission Power 23dBm, max. (2.4GHz)
    22dBm, max. (5GHz)
