TP-Link EAP225-Wall

Categories: , .

TP-Link EAP225-Wall

TP-Link Wireless Wall-Plate Access Point
EAP225-Wall

  • AC1200 wireless with 100Mbps Ethernet backhaul
  • Designed for office cubical and hotel room wired and wireless connections
  • Easy-mount construction allows installation into 1-gang electric wall-box
  • Compact, low-profile design fits discreetly with any existing interior style
  • Cloud management and Omada App supported for ultra convenience and easy management
  • Power over Ethernet (802.3af/802.3at) support makes deployment effortless and flexible
  • Enterprise-class Wi-Fi security helps to decrease network security threats
  • Supports management VLAN for an enhanced network management
  • HARDWARE FEATURES
    Interface 1 × 10/100Mbps Ethernet uplink port accepts 802.3af/at power supply as PoE power device (PD)
    2 × 10/100Mbps Ethernet Port
    1 × 10/100Mbps with PoE pass-thru (requires 802.3at PoE+ power supply on PD port.)
    Physical Security Lock Yes
    Button Reset
    Power Supply 802.3af or 802.3at PoE
    Power Consumption 9 watts or
    25.5 watts including PoE Out
    Dimensions 5.6 × 3.4 × 0.8 in.
    (143 × 86 × 19.7mm)
    Antenna 2 Dual-Band Antennas
    2.4GHz: 2 × 3dBi
    5GHz: 2 × 4dBi
    Mounting Wall Plate Mounting



  • WIRELESS FEATURES
    Wireless Standards IEEE 802.11n/g/b/ac
    Frequency 2.4GHz and 5GHz
    Signal Rate 5GHz: Up to 867Mbps
    2.4GHz: Up to 300Mbps
    Wireless Functions 16 SSIDs(Up to 8 SSIDs on each band)
    Enable/Disable Wireless Radio
    Automatic Channel Assignment
    Transmit Power Control (Adjust Transmit Power on dBm)
    QoS(WMM)
    Load Balance
    Rate Limit
    Reboot Schedule
    Wireless Schedule
    Wireless Statistics based on SSID/AP/Client
    Wireless Security Captive Portal Authentication
    Access Control
    Wireless Mac Address Filtering
    Wireless Isolation Between Clients
    SSID to VLAN Mapping
    Local LAN port based VLAN
    Rogue AP Detection
    802.1X Support
    64/128/152-bit WEP / WPA / WPA2-Enterprise,
    WPA-PSK / WPA2-PSK
    Transmission Power 21dBm max. (2.4 GHz)
    21 dBm max. (5 GHz)
