TP-Link EAP115

N300 Wireless N Ceiling Mount Access Point

  • Omada cloud software controller center controls hundreds of EAPs
  • Powered by standard 802.3af PoE for convenient installation
  • Simple mounting design for easy attachment to a wall or ceiling
  • Web captive portal provides a professional and convenient way to get the Wi-Fi access
  • Advertising page, Facebook Wi-Fi and SMS authentication help to boost your business
  • Enterprise-class Wi-Fi security help to lower network security threats
  • Multi-SSIDs separates the different groups of users with different resource privileges
  • Supports management VLAN for an enhanced network management
    Interface Fast Ethernet (RJ-45) Port x 1
    (IEEE802.3af PD)
    Physical Security Lock Kensington Lock Slot
    Button Reset
    Power Supply 802.3af PoE or
    external 9VDC/0.6A power supply
    Power Consumption 2.8W
    Dimensions 7.5×6.8×1.2 in.
    (189 × 172 × 30 mm)
    Antenna Type 2 x Internal 4dBi Omni
    Mounting Ceiling or wall mounting (mounting kit included)


    Wireless Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
    Frequency 2.4-2.4835GHz
    Signal Rate 11n: Up to 300Mbps(dynamic)
    11g: Up to 54Mbps(dynamic)
    11b: Up to 11Mbps(dynamic)
    Reception Sensitivity 300M: -71dBm@10% PER
    150M: -75dBm@10% PER
    54M: -78dBm@10% PER
    11M: -93dBm@8% PER
    6M: -92dBm@10% PER
    1M: -96dBm@8% PER
    Wireless Functions Multiple SSIDs (Up to 8 SSIDs)
    Enable/Disable Wireless Radio
    Automatic Channel Assignment
    Transmit Power Control (adjustable on 1 dBm step)
    QoS (WMM)
    Rate Limit
    Reboot Schedule
    Wireless Schedule
    Wireless Statistics based on SSID/AP/Client
    Wireless Security Captive Portal Authentication
    Access Control
    Wireless Mac Address Filtering
    Wireless Isolation Between Clients
    SSID to VLAN Mapping
    Rogue AP Detection
    802.1X Support
    64/128/152-bit WEP / WPA / WPA2-Enterprise,WPA-PSK / WPA2-PSK
    Transmission Power < 21dBm
