TP-Link EAP110-Outdoor

Categories: , .

TP-Link EAP110-Outdoor

N300 Wireless N Outdoor Access Point

  • Built for outdoor Wi-Fi applications
  • Up to 300Mbps1 Wi-Fi with 2×2 MIMO technology
  • High transmission power and high gain antennas provide a long-range coverage area
  • Durable, weatherproof enclosure to withstand fair and foul weather
  • Passive PoE(Power over Ethernet) support and simple mounting design allow for flexible deployment and convenient installation
  • Auranet Controller Software lets administrators easily manage hundreds of EAPs
  • Captive portal provides a convenient method for guest authentication
  • Supports management vlan for an enhanced network management
    Interface 1 × Fast Ethernet (RJ-45) Port
    (Support Passive PoE)
    Button Reset
    Power Supply 24V Passive PoE
    (+4,5pins; -7,8pins. PoE Adapter Included)
    Power Consumption 3.1 W
    Dimensions ( W x D x H ) 8.2 × 3.7 × 1.7 in.
    (209 × 95 × 42.6 mm)
    Antenna Type 2 × 3dBi External Omni waterproof
    Weatherproof Enclosure IP65
    Mounting Pole or wall mounting (mounting kit included)


    Wireless Standards IEEE 802.11n/g/b
    Frequency 2.4GHz
    Signal Rate 11n: Up to 300Mbps*
    11g: Up to 54Mbps*
    11b: Up to 11Mbps*
    Transmit Power < 27dBm
    Wireless Functions Multiple SSIDs (Up to 8 SSIDs)
    Enable/Disable Wireless Radio
    Automatic Channel Assignment
    Transmit Power Control (adjustable on 1 dBm step)
    QoS (WMM)
    Load Balance
    Rate Limit
    Reboot Schedule
    Wireless Schedule
    Wireless Statistics based on SSID, AP, and Client
    Wireless Security Captive Portal Authentication
    Access Control
    Wireless Mac Address Filtering
    Wireless Isolation Between Clients
    SSID to VLAN Mapping
    Rogue AP Detection
    802.1X Support
    64/128/152-bit WEP / WPA / WPA2-Enterprise,
