Ubiquiti USG-PRO

Ubiquiti USG-PRO

USG-PRO

Enterprise Gateway Router with Gigabit Ethernet
The UniFi® Security Gateway Pro extends the UniFi Enterprise System to provide cost-effective, reliable routing and advanced security for your network.

Model: USG‑PRO‑4
Optical Fiber Connectivity
The UniFi Security Gateway Pro offers two optional SFP ports for fiber connectivity to support backhaul applications
Rackmount Design
The UniFi Security Gateway Pro is housed in a durable, rackmount chassis.
Powerful Firewall Performance
The UniFi® Security Gateway offers advanced firewall policies to protect your network and its data.
Convenient VLAN Support
The UniFi® Security Gateway Pro can create virtual network segments for security and network traffic management.

Specifications
UniFi USG-PRO-4
Dimensions 484 x 44 x 164 mm
(19.06 x 1.73 x 6.46")
Weight 2.3 kg
(5.07 lb)
Max. Power Consumption 40W
Power Supply Internal AC/DC Power Adapter, 60W (24V, 2.5A)
Power Input 110 - 240VAC
LEDs
System
Data Ports
Status
Speed/Link/Activity
Networking Interfaces
Serial Console Port
Data Ports
(1) RJ45 Serial Port
(2) 10/100/1000 RJ45 LAN Ports
(2) 1 Gbps RJ45/SFP Combination WAN Ports
Layer 3 Forwarding Performance
Packet Size: 64 Bytes
Packet Size: 512 Bytes or Larger
2,400,000 pps
4 Gbps (Line Rate)
Processor Dual-Core 1 GHz, MIPS64 with Hardware Acceleration for Packet Processing
System Memory 2 GB DDR3 RAM
On-Board Flash Storage 4 GB
Certifications CE, FCC, IC
Rackmount Yes
Operating Temperature -10 to 45° C
(14 to 113° F)
Operating Humidity 10 to 90% Noncondensing
