Model
QR600-HK / QR600-H / QR600-VK / QR600-V
QR Sensor
QR, Data Matrix, PDF417, GS1 Databar, Code 128 / EAN128,UPC / EAN, Codabar, Code 39 / Code 93 etc.
RFID
125kHz ID crads / 13.56MHz IC Cards
Reading Distance
QR Code ≥ 5cm; RFID Card ≥ 4cm
Communication
Wiegand & RS485
Ingress Protection Rating
IP65
Power Supply
DC 12V (±5%)
Operating Temperature
-20°C to 60°C
Storage Temperature
-20°C to 80°C
Operating Humidity
20% to 80% (assuming the working environment temp. is 25°C)
Dimension
QR600-HK / QR600-H: 120 * 80 * 16 (mm) (L*W*H)
QR600-VK / QR600-V: 138 * 58 * 16 (mm) (L*W*H)
