APC Smart-UPS 5000VA 230V Rackmount/Tower

Categories: , .

APC Smart-UPS 5000VA 230V Rackmount/Tower

APC Smart-UPS 5000VA 230V Rack mount/Tower is an ideal power source for servers, network devices such as the routers, switches, hubs, modems and others. This smart UPS has the reliable battery backup capacity to power through outrages or smoothly shutdown systems. The system is highly appreciated for its performance with the ability for reducing utility costs and less heat generation. The system comes with rack mounting hardware and support rails that protects UPS when migrating from tower to rack mount environment.

Features

  • High online efficiency
  • Intuitive LCD interface
  • Adjustable voltage-transfer points
  • Adjustable voltage sensitivity
  • Avoid costly power problems
  • Save time with easy and convenient remote accessibility
  • USB connectivity

You can place the order online for APC Smart-UPS 5000VA 230V Rack mount/Tower through Amaze Technologies.

Description
SUA5000RMI5U Features
APC Smart-UPS 5000VA 230V Rackmount/Tower
Intelligent and efficient network power protection from entry level to scaleable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices.
Includes: CD with software, Documentation CD, Installation Guide, Rack mounting hardware, Rack Mounting support rails, Smart UPS signalling RS-232 cable, User Manual, Web/SNMP Management Card
Adjustable voltage-transfer points
Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation.
Audible alarms
Provides notification of changing utility power and UPS power conditions
Automatic self-test
Periodic battery self-test ensures early detection of a battery that needs to be replaced.
Boost and Trim Automatic Voltage Regulation (AVR)
Gives higher application availability by correcting low and high voltage conditions without using the battery (not available on all models).
Cold-start capable
Provides temporary battery power when the utility power is out.
Disconnected battery notification
Warns when a battery is not available to provide backup power.
Hot-swappable batteries
Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
Network manageable
Provides remote power management of the UPS over the network.
Rack/Tower convertible
Protects the initial investment in the UPS when migrating from tower to rack-mount environment.
Resettable circuit breakers
Enables a quick recovery from overload events.
Safety-agency approved
Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.
Serial connectivity
Provides management of the UPS via a serial port.
SmartSlot
Customize UPS capabilities with management cards.
Temperature-compensated battery charging
Prolongs battery life by regulating the charge voltage according to battery temperature.
Smart-UPS Features & Benefits
Availability
Intelligent battery management

Maximizes battery performance, life, and reliability through intelligent, precision charging.
Boost and Trim Automatic Voltage Regulation (AVR)

Gives higher application availability by correcting low and high voltage conditions without using the battery (not available on all models).
Temperature-compensated battery charging

Prolongs battery life by regulating the charge voltage according to battery temperature.
Power conditioning

Protects connected loads from surges, spikes, lightning, and other power disturbances.
Automatic self-test

Periodic battery self-test ensures early detection of a battery that needs to be replaced.
Automatic restart of loads after UPS shutdown

Automatically starts up the connected equipment upon the return of utility power.
Disconnected battery notification

Warns when a battery is not available to provide backup power.
Marketing Features
Avoids costly power problems by keeping your IT equipment and data safe and available

Network grade power conditioning protects from damaging surges and disruptive noise. Solid state automatic voltage regulation boosts low input voltage up to 30% and trims high voltage up to 12% without battery operation. Reliable battery back-up capacity to power through outages or gracefully shutdown systems
Save time with easy and convenient remote accessibility

Network manageable via serial, USB or optional ethernet. Includes Powerchute® Business Edition Software for convenient monitoring and control, safe operating system shutdown and innovative energy management capabilities.
Technical Specifications
Output
Output power capacity

4.0kWatts / 5.0kVA
Max Configurable Power (Watts)

4.0kWatts / 5.0kVA
Nominal Output Voltage

230V
Output Voltage Note

Configurable for 220 : 230 or 240 nominal output voltage
Efficiency at Full Load

96.0 %
Output Voltage Distortion

Less than 5% at full load
Output Frequency (sync to mains)

47 – 53 Hz for 50 Hz nominal
Other Output Voltages

220, 240
Topology

Line Interactive
Waveform type

Sine wave
Output Connections

(4) IEC Jumpers (Battery Backup)
(2) IEC 320 C19 (Battery Backup)
