Christie LCD Panel Secure Series II TAA-compliant panels SUHD863-L

86” 4K UHD 450 nit LCD panel designed for secure operation.

Share:

Native resolution
4K UHD 3840 x 2160 (16:9)

Backlight
Edge-lit LED

LED lifespan
30,000 hours to 50% brightness

Display orientation
Landscape

Pixel pitch (WxH)
0.493 x 0.493mm

Bezel size (bottom/side/top)
19mm/19mm/19mm

Brightness (typical) – (cd/sq m)
450 nits

Contrast ratio (typical)
1,200:1

Viewing angle (CR 10:1)
178 degrees h/v

Refresh rate
60Hz

Response time (typical)
8ms

Color space typical (CIE 1931)
72% typical

Display colors
10 bit, 1.07 billion

Video inputs
4 x HDMI (Ver 2.0b, HDCP 2.2)
DisplayPort Ver 1.2
OPS

Audio outputs
3.5mm headphone jack

Control inputs
RS-232 via D-Sub9
LAN via RJ45
IR wire extender
USB-A2.0 for service

Power input rating
100-240 VAC @ 50/60Hz

Power consumption
350W maximum without OPS
0.5W standby without OPS

Operating temperature
32-104°F (0-40°C)

Storage temperature
-4-140°F (-20-60°C)

Operating humidity
20-90% RH non-condensing

​Physical size (panel only)
(WxHxD): 76.3 x 43.7 x 2.7″ (1939 x 1110 x 69mm)

Weight
110lbs (50kg)

Mounting
VESA (WxH) 600 x 400mm
M8

Runtime
Recommended for 18/7 operation featuring a reliable power supply*

Features
Commercial-grade LCD with LED backlight
OPS slot
Anti-glare treatment
2 x 15W speakers
HDMI-CEC
DICOM simulation
HDR10 compatible
Priority Input Source
Source switching for failover
No RF capability
4 window multi-source UHD viewing (Quadview, PiP, PBP)
MEMC Crestron Connected 2

Brand

Christie
