Christie LCD Panel Secure Series II TAA-compliant panels SUHD983-P

98” 4K UHD 500 nit LCD secure panel designed for 24/7 operation with 4K@60Hz resolution, portrait and landscape capable

Share:

Native resolution
4K UHD 3840 x 2160 (16:9)

Backlight
Direct-lit LED

LED lifespan
50,000 hours to 50% brightness

Display orientation
Portrait and landscape

Pixel pitch (WxH)
0.57 x 0.57mm

Bezel width
16mm

Brightness (typical) – (cd/sq m)
500 nits

Contrast ratio (typical)
1,200:1

Viewing angle (CR 10:1)
178 degrees h/v

Refresh rate
120Hz

Response time (typical)
8ms

Color space typical (CIE 1931)
72%

Display colors
10 bit, 1.07 billion

Video inputs
4 x HDMI™ (Ver 2.0b, HDCP 2.2)
DisplayPort™ (Ver 1.4)
OPS

Audio outputs
3.5mm headphone jack

Control inputs
RS-232 (D-Sub9)
LAN (RJ45)
IR wire extender
USB-A2.0 for service

Power input rating
110-240 VAC @ 50/60Hz

Power consumption
600W maximum (without OPS)
<=0.5W in standby (without OPS) Operating temperature 32-104°F (0-40°C) Storage temperature -4-140°F (-20-60°C) Operating humidity 20-90% RH non-condensing Size (panel only) (WxHxD) 86.4 x 49.2 x 3.8" (2195 x 1250 x 96mm) Weight 209.4lbs (95kg) Mounting VESA 800mm x 400mm, M8 Runtime Designed for 24/7 operation featuring a reliable power supply* Features Commercial-grade LCD with LED backlight OPS slot Anti-glare treatment 2 x 15W speakers HDMI-CEC DICOM simulation HDR10 compatible Priority Input Source Source switching for failover No RF capability 4 window multi-source UHD viewing (Quadview, PiP, PBP) MEMC Crestron Connected 2 Accessories Panel ships with IR remote control HDMI 2.0 3M cable External IR receiver Power cable Product safety guide Warranty Three years parts and labor limited warranty Contact an authorized Christie representative for full details of our limited warranty

Brand

Christie
