Dell Server PowerEdge R230 Rack

Powerful, efficient, versatile.
Consolidate data and drive applications faster with the powerful, efficient and versatile PowerEdge R230 1-socket, 1U entry rack server.

Get organized and become more productive
Consolidate data from multiple laptops or desktops onto a single server with up to 4 x internal 3.5″ cabled or hot-plug HDD.
Ensure fast response times with the latest quad core Intel® Xeon® E3-1200 v6 product family, as well as flexible dual core processor options including Intel Pentium®, Intel Core i3®, or Intel Celeron®.
Adapt to changing workload conditions with a virtualization-ready server supporting Citrix® XenServer®, Microsoft® Windows Server® with Hyper-V®, VMware® vSphere® ESXi®, and Red Hat® Enterprise Virtualization.
Accelerate application performance
Drive greater memory performance and expand capacity up to 64GB through time with 4 x DIMM slots and enhanced DDR4 memory, offering 50% faster clock speed than previous-generation DDR3 which is 12.5% faster than the initial 2133 MT/s implementation of DDR4.1
Boost data throughput with 2 x PCIe Gen 3.0 slots driving 2x data throughput compared to Generation 2.0.
Drive 2x IOPS performance with the PowerEdge PERC9 RAID Controller compared to the previous-generation PowerEdge R220 equipped with PERC8.2

Processor
1 processor from the following product families:
Intel® Xeon® processor E3-1200 v6 product family
Intel Pentium®
Intel Core i3®
Intel Celeron®
Operating System
Microsoft® Windows Server® 2012
Microsoft Windows Server 2012 R2, x64
Microsoft® Windows Server® 2016
Red Hat® Enterprise Linux®
VMware Vsphere® ESXi®
SUSE® Linux Enterprise Server®
Memory4
Architecture: Up to 2400MT/s DDR4 DIMMs
Memory Type: UDIMMs
Memory Module Sockets: 4
Maximum RAM: Up to 64GB
Drive Bays
2 x 3.5" cabled HDD
4 x 3.5" cabled HDD
4 x 3.5" hot swap or 2.5" hot swap in hybrid drive carrier
Dimensions & Weight
Depth without bezel: 495.0 mm (19.5 in)
Depth with bezel: 551.3 mm (21.7 in)
Height: 42.8 mm (1.68 in)

Width without rack latches: 434.0 mm (17.08 in)
Width with rack latches: 482.4 mm (18.99 in)
Chassis
2 x 3.5" cabled HDD 19.5" 1U chassis
4 x 3.5" cabled HDD 19.5" 1U chassis
4 x 3.5" Hot-Plug HDD 19.5" 1U chassis
Power
250W cabled PSU
RAID Controllers
S130, H330, H730, H830
Chipset
Intel C236
Storage
2.5” SATA 7.2K
2.5” nearline SAS 7.2K
2.5” 10K SAS HDDs
2.5” 15K SAS HDDs
2.5” SATA HDDs
3.5” Enterprise SATA 7.2K HDDs
3.5” nearline SAS 7.2K HDDs
3.5” 7.2K SATA entry drives
Slots
2 x PCIe 3.0 slots: x16 slot, full height (1x8 PCIe 3.0)+ x8 slot, low profile (1x4 PCIe 3.0)
Network Controller
Broadcom® BCM5720
Management
Systems management:
IPMI 2.0 compliant
Dell OpenManage Essentials
Dell OpenManage Mobile
Dell OpenManage Power Center

Dell OpenManage Integrations:
Dell OpenManage Integration Suite for Microsoft System Center
Dell OpenManage Integration for VMware vCenter™

Dell OpenManage Connections:
HP Operations Manager, IBM Tivoli® Netcool® and CA
Network and Systems Management
Dell OpenManage Plug-in for Oracle® Database Manager

Remote management:
iDRAC8 with Lifecycle Controller, iDRAC8 Express (default),
iDRAC8 Enterprise (upgrade), 8GB vFlash media (upgrade),16GB vFlash media (upgrade)
Embedded Hypervisor (Optional)
Hypervisor Support

Microsoft Windows Server with Hyper-V®
VMware® vSphere® ESXi®
Communications
2 x 1GbE LOM
Device Access
5 Total USB:
Rear: 2 x USB 3.0 ports
Front: 2 x USB 2.0 ports
Internal: 1 x USB 3.0 port
Rack Support
ReadyRails™ static rails for tool-less mounting in 4-post racks with square or unthreaded round holes or tooled mounting in 4-post threaded and 2-post racks
