Dell Server R840 Rack

Categories: , .

Dell Server R840 Rack

Turbocharge your data analytics
Drive faster insights with four-socket performance in a dense 2U design. Minimize latency with up to 24 direct-attached NVMe drives.

Power your business-critical workloads
The PowerEdge R840 accelerates business insights and delivers unprecedented performance density for your in-database analytics. Deliver consistent results for demanding applications with powerful, four-socket performance and large memory. Even as your workloads become more complex, OpenManage™ Enterprise simplifies management of your IT infrastructure so you can focus on your business objectives. Integrated security and proven reliability helps ensure maximum uptime in your enterprise data center.

Ideal workloads:
Data intensive applications
Data analytics

Scale application performance for demanding data analytics workloads
The R840 offers versatile resources that allow you to meet changing business demands. Maximize performance and minimize latency with direct-attached NVMe drives.

Boost performance with up to four 2nd Generation Intel® Xeon® Scalable processors and up to 112 processing cores
Address large data sets with up to 48 DIMMs (24 of which can be DCPMMs) and up to 15.36TB of memory
Scale capacity and performance with up to 26 2.5” HDDs/SSDs (up to 24 NVME drives)
Accelerate applications with two doublewide GPUs or two FPGAs
Speed data transfers with fully integrated ultra path interconnects (UPIs)



Processor
Up to four 2nd Generation Intel® Xeon® Scalable processors with up to 28 cores per processor
Accelerators
Up to two double-width GPUs
Up to two full-height FPGAs
Memory2
DIMM Speed
Up to 2933MT/s

Memory Type
RDIMM
LRDIMM
NVDIMM
DCPMM (Intel® Optane™ DC persistent memory)

Memory Module Slots
48 DDR4 DIMM slots (12 NVDIMM or 24 DCPMM slots only)
Supports registered ECC DDR4 DIMMs only

Maximum RAM
RDIMM 3TB
LRDIMM 6TB
NVDIMM 384GB
DCPMM 12.28TB (15.36TB with LRDIMM)
Storage Controllers
Internal Controllers
PERC H330, H730P, H740P, HBA330

Software RAID
S140

External HBAs (non-RAID)
12Gbps SAS HBA

External PERC (RAID)
H840

Boot Optimized Storage Subsystem
HWRAID 2 x M.2 SSDs 240GB or 480GB
Power Supplies
750W Platinum
750W 240VDC3Platinum
750W Titanium
1100 Platinum
1100W 240VDC3 Platinum
1100W - 48VDC Gold
1600W Platinum
2000W Platinum
2400W Platinum
Hot plug power supplies with full redundancy option
Up to 6 hot plug fans with N +1 redundancy
Dimensions & Weight
Height
86.8mm (3.4”)

Width
434.0mm (17.8")

Depth
835.9mm (32.9")

Weight
36.6kg (80.7lbs.)
Bezel
Optional LCD bezel or security bezel
Security
Cryptographically signed firmware
Secure Boot
Secure Erase
Silicon Root of Trust
System Lockdown (requires OpenManage Enterprise)
TPM 1.2/2.0, TCM 2.0 optional
Supported Operating Systems
Canonical® Ubuntu® Server LTS
Citrix® Hypervisor
Microsoft® Windows Server® LTSC with Hyper-V
Oracle® Linux
Red Hat® Enterprise Linux
SUSE® Linux Enterprise Server
VMware® ESXi®
Recommended Support
Choose Dell ProSupport Plus for critical systems or Dell ProSupport for premium hardware and software support for your PowerEdge solution. Consulting and deployment offerings are also available. Contact your Dell representative today for more information. Availability and terms of Dell Services vary by region.
Ports
Network Options
4 x 1GbE
4 x 10GbE
2 x 10GbE + 2 x 1GbE
2 x 25GbE

Front Ports
1 x Dedicated iDRAC direct USB
2 x USB 2.0
1 x USB 3.0 (optional on the 8-drive configuration only)
1 x VGA

Rear Ports
1 x Dedicated iDRAC port
1 x Serial
2 x USB 3.0
1 x Video

Internal Ports
1 x USB 3.0
Storage
Front Bays
Up to 8 x 2.5” SAS/SATA (HDD/SSD) max 61.44TB
Up to 24 x 2.5” SAS/SATA (HDD/SSDs) with up to 12 NVMe PCIe SSDs max 184.32TB
Up to 24 x NVMe PCIe SSDs max 153TB

Rear Bays
Up to 2 x 2.5” SAS/SATA (HDD/SSD), max 15.36TB
Slots
PCIe
6 x Gen3 slots

Video Card
1 x VGA
Management
Embedded / At-the-Server
iDRAC9
iDRAC RESTful API with Redfish
iDRAC Direct
Quick Sync 2 BLE/wireless module

Consoles
OpenManage Enterprise
OpenManage Power Center

Mobility
OpenManage Mobile

Tools
Dell EMC RACADM CLI
Dell EMC Repository Manager
Dell EMC System Update
Dell EMC Server Update Utility
Dell EMC Update Catalogs
iDRAC Service Module
IPMI Tool
OpenManage Server Administrator
OpenManage Storage Services

OpenManage Integrations
BMC Truesight
Microsoft® System Center
RedHat® Ansible® Modules
VMware® vCenter

OpenManage Connections
IBM Tivoli Netcool/OMNIbus
IBM Tivoli® Network Manager IP Edition
Micro Focus Operations Manager I
Nagios® Core
Nagios® XI
