4K Network IR Bullet Camera
The PNO-9080R from Hanwha’s Wisenet P Series Performance IP camera line is a 4K, 12MP outdoor bullet featuring Hanwha’s WiseStream technology, triple codec H.265/H.264/MJPEG, motorized vari-focal 4.5~10mm lens, True D/N, True WDR (120dB), IR (40m), edge analytics, SD card slot (SD/SDHC/SDXC up to 128GB), digital auto tracking, Hallway view, IK10/IP66, supports PTZ handover function.

VIDEO
Imaging Device 1/1.7" 12.4M CMOS
Total Pixels/ Eective Pixels 4,168(H) x 3,062(V) / 4,072(H) x 3,046(V)
Scanning System Progressive
Min. Illumination Color : 0.3Lux (1/30sec, F1.6, 30IRE), 0.01Lux (2sec, F1.6, 30IRE)
B/W : 0Lux (IR LED on)
S / N Ratio 50dB
Video Output CVBS : 1.0 Vpp / 75Ω composite, 714 x 480(N), 702 x 576(P), for installation
DIP connector type
LENS
Focal Length (Zoom Ratio) 4.5 ~ 10mm (2.2x) motorized varifocal
Max. Aperture Ratio F1.6
Angular Field ofView [4096 x 2160] H : 100.3˚(Wide) ~ 45.6˚(Tele)/ V : 49.7˚(Wide) ~ 24.0˚(Tele)
[3840 x 2160] H : 92.3˚(Wide) ~ 42.6˚(Tele) / V : 49.7˚(Wide) ~ 24.0˚(Tele)
Min. Object Distance 0.5m (1.64ft)
Focus Control Simple focus(Motorized V/F)/ Manual, Remote control via network (Manual, Simple focus)
Lens Type / Mount Type P-Iris mode / Board-in type
OPERATIONAL
IRViewable Length 40m (131.23ft)
Camera Title
O / On (Displayed up to 60 characters) - W/W : English / Numeric / Special characters - China : English / Numeric / Special/ Chinese characters - Common : Multi-line (Max. 5), Color (Grey / Green / Red / Blue / Black / White),
Transparency, Auto scale by resolution
Day & Night Auto (ICR)/ Color/ B/W / External/ Schedule
Backlight Compensation O / BLC / WDR
Wide Dynamic Range 120dB
Contrast Enhancement SSDR (O / On)
Digital Noise Reduction SSNR (2D+3D noise lter) (O / On)
Defog O / Auto / Manual
Motion Detection O / On (8ea, Polygonal)
Privacy Masking O / On (16ea, Polygonal) - Color : Gray / Green / Red / Blue / Black / White
Gain Control O / Low / Middle / High
White Balance ATW / AWC / Manual / Indoor/ Outdoor (Include mercury & sodium)
Electronic Shutter Speed Minimum / Maximum / Anti icker (2 ~ 1/12,000sec)
Flip / Mirror O / On, Hallway : 90° /270°
IntelligentVideo Analytics Tampering (Scene change), Virtual line, Enter/ Exit, (Dis)Appear, Audio detection,
Defocus detection, Digital auto tracking - with metadata
Alarm I/O Input 1ea / Output 1ea
AlarmTriggers Alarm input, Motion detection, Video analytics, Audio detection, Network disconnect
Alarm Events File upload via FTP and E-mail, Notication via E-mail
Localstorage (SD/SDHC/SDXC) or NAS recording at event triggers, External output
Pixel Counter Support (Plug-in viewer only)
NETWORK
Ethernet RJ-45 (10/100/1000BASE-T)
Video Compression Format H.265 / H.264 (MPEG-4 part 10/AVC) : Main / Baseline / High, MJPEG
Resolution
[8M mode] 4096 x 2160, 3840 x 2160, 2592 x 1944, 2592 x 1464, 1920 x 1080, 1600 x 1200, 1280 x 1024,
1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 800 x 448, 720 x 576, 720 x 480, 640 x 480, 640 x 360, 320 x 240
[12M mode] 4000 x 3000, 3840 x 2160, 2592 x 1944, 2592 x 1464, 1920 x 1080, 1600 x 1200, 1280 x 1024,
1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 800 x 448, 720 x 576, 720 x 480, 640 x 480, 640 x 360, 320 x 240
Max. Framerate H.265 / H.264 : [email protected] x 3000, [email protected] x 2160
MJPEG : [email protected] x 3000 ~ 2592 x 1464, [email protected] x 1080 ~ 320 x 240
Smart Codec /WiseStream Manual mode (Area-based : 5ea) / Support
VideoQuality Adjustment H.265 / H.264 : Target bitrate level control, MJPEG : Quality level control
Bitrate Control Method H.265 / H.264 : CBR or VBR, MJPEG : VBR
Streaming Capability Multiple streaming (Up to 3 proles)
Audio In Selectable (Mic in / Line in), Supply voltage : 2.5V DC (4mA), Input impedance : approx. 2K Ohm
Audio Out Line out (3.5mm mono jack), Max output level : 1Vrms
Audio Compression Format G.711 u-law/G.726 selectable, G.726 (ADPCM) 8KHz, G.711 8KHz G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps, AAC-LC : 48Kbps at 16KHz
Audio Communication Bi-directional audio (2-way)
IP IPv4, IPv6
Protocol TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE,
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour
Security
HTTPS(SSL) login authentication, Digest login authentication
IP address ltering, User accesslog, 802.1x authentication (EAP-TLS, EAP-LEAP)
Streaming Method Unicast / Multicast
Max. User Access 15 users at unicast mode
Edge Storage
SD/SDHC/SDXC (128GB) - Motion imagesrecorded in the SD/SDHC/SDXC memory card
can be downloaded, Camera can detect automatically when the memory is connected,
Memory status display (Normal / Error/ Active / Formatting / Lock),
NAS (Network Attached Storage), Local PC for instant recording (Plug-in viewer only)
Application Programming Interface ONVIF prole S/G, SUNAPI (HTTP API), SVNP, Wisenet Open Platform
Webpage Language English, French, German, Spanish, Italian, Chinese, Russian, Japanese,
Swedish, Portuguese, Turkish, Polish, Czech, Dutch, Hungary, Greek
WebViewer
Supported OS : Windows 7, 8.1, 10, Mac OS X 10.9, 10.10, 10.11
Plug-in free Webviewer
- Supported Browser : Google Chrome 47, MS Edge 20
Plug-in Webviewer - Supported Browser : MS Explore 11, Mozilla Firefox 43, Apple Safari 9 * Mac OS X only
Central Management Software SmartViewer
ENVIRONMENTAL
OperatingTemperature / Humidity
-40°C ~ +55°C (-40°F ~ +131°F)/ Lessthan 90% RH * Start up should be done at above -35°C (-31°F)
Storage Temperature / Humidity -40°C ~ +60°C (-40°F ~ +140°F)/ Lessthan 90% RH
Ingress Protection /Vandal Resistance IP66 / IK10
ELECTRICAL
InputVoltage / Current 24V AC, 12V DC, PoE (IEEE802.3af, Class3)
Power Consumption 12V DC : Max. 11.55W, PoE : Max.12.95W, 24V AC (50/60Hz) : 14.08W - Heater on
12V DC : Max. 10.45W, PoE : Max.11.77W, 24V AC (50/60Hz) : 12.43W - Heater o
