TP Link RE650

Categories: , .

TP Link RE650

AC2600 MU-MIMO Wi-Fi Range Extender, Wall Plugged, 4 external antennas, 1 Gigabit Port, 1733Mbps at 5GHz + 800Mbps at 2.4GHz, Range Extender/AP mode, WPS, 4×4 MU-MIMO, Beamforming, Intelligent Signal Light, Access Control, Power Schedule, LED Control, Tether App

HARDWARE FEATURES
Plug Type US
Standards and Protocols IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.11a
Interface 1x 10/100/1000M Ethernet Port (RJ45)
Button WPS Button, Reset Button, LED Button, Power Button
Power Consumption 12W(max power consumption)
Dimensions ( W x D x H ) 6.4x 3.4 x 1.6 in. (163 x 86 x 40mm)
Antenna 4x external
WIRELESS FEATURES
Frequency 2.4GHz & 5GHz(11ac)
Signal Rate 5GHz:Up to 1733Mbps
2.4GHz:Up to 800Mpbs
Reception Sensitivity 5GHz:
11a 6Mbps:-96dBm@10% PER
11a 54Mbps: -78dBm@10% PER
11ac HT20 mcs8: -69dBm@10% PER
11ac HT40 mcs9: -66dBm@10% PER
11ac HT80 mcs9: -63dBm@10% PER
2.4GHz
11g 54M: -79dBm@10% PER
11n HT20 mcs7: -77dBm@10% PER
11n HT40 mcs7: -74dBm@10% PER
Wireless Modes Range Extender/Access Point
Wireless Functions Wireless Statistic
Concurrent Mode boost both 2.4G/5G WiFi band
High Speed Mode for great speed for HD Gaming and video
Access Control
LED Control
Domain Login Function
Wireless Security 64/128-bit WEP
WPA-PSK / WPA2-PSK
Transmission Power <20dBm(2.4GHz)
<23dBm(5GHz)
OTHERS
Certification FCC, RoHS
Package Contents AC2600 Wi-Fi Range Extender RE650
Quick Installation Guide
Box Dimensions (W X D X H) 7.9 x 4.9 x 3.8in. (202x 125 x 97mm)
System Requirements Microsoft® Windows® 98SE, NT, 2000, XP, Vista or Windows 7, 8, 10, Mac® OS, NetWare®, UNIX® or Linux.
Environment Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
